Поз.
Артикул
Описание
5
RADIATOR WITH SCREW FITTING,K 115008
5
RADIATOR , Replaced By: A6525016901
5
RADIATOR ,K 115007
5
RADIATOR ,K 115007
5
RADIATOR , Replaced By: A6525014901
5
RADIATOR
5
RADIATOR WITH SCREW FITTING
5
RADIATOR , Replaced By: A6525014201
5
RADIATOR , Replaced By: A6525014201
5
RADIATOR , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 752618, Replaced By: A6525012501
11
SCREW WATER DRAIN
13
SCREW WATER DRAIN
13
SCREW , Replaced By: A0005000085
15
GASKET COOLING WATER DRAIN TO 656 500 00 03
16
LOCK
29
RUBBER MOUNTING RADIATOR
32
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
32
SCREW , Replaced By: N304017010028
35
WASHER RADIATOR TO RUBBER MOUNTING
35
WASHER , Replaced By: N000125010532
38
FAN SHROUD
38
FAN SHROUD RADIATOR
41
DETENT FAN SHROUD TO RADIATOR
50
LOCK PULL TO FASTENER
50
LOCK , Replaced By: N912002008003
56
BOOT FAN SHROUD TO FAN RING
56
BOOT , Replaced By: A6565050286
56
BOOT FAN SHROUD TO FAN RING
57
BOOT (SEALING LIP)
58
BRACKET SEALING LIP TO RADIATOR
59
BRACKET SEALING LIP TO OIL DIPSTICK BRACKET
59
BRACKET SEALING LIP TO OIL DIPSTICK BRACKET
60
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
61
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
61
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
62
BRACKET SEALING LIP TO EXPANSION TANK
63
PIN SEALING LIP TO EXPANSION TANK
64
TANK COOLING WATER EXPANSION
65
RADIATOR CAP FILLER NECK
65
RADIATOR CAP , Replaced By: A0005016415
66
SEAL RING
68
RADIATOR CAP
71
RADIATOR CAP CENTRAL
71
RADIATOR CAP CENTRAL
74
GASKET O.D., 52 MM
77
GASKET O.D., 37 MM
80
DRAIN PIPE
83
SENDER UNIT COOLING WATER LEVEL INDICATOR
86
PLATE FROM EXPANSION TANK TO RADIATOR
86
PLATE FROM EXPANSION TANK TO RADIATOR 40X40 MM
89
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
92
HOSE FROM EXPANSION TANK TO ENGINE
95
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
95
CLAMP , Replaced By: N916017011001
140
BRACKET OIL DIPSTICK GUIDE TUBE
146
BRACKET OIL DIPSTICK GUIDE TUBE TO BRACKET
146
BRACKET OIL DIPSTICK GUIDE TUBE
149
SCREW DE-AERATION LINE TO RADIATOR
149
SCREW , Replaced By: A6739900032
152
SCREW PUMP TO BRACKET
152
SCREW , Replaced By: N304017006016
152
SCREW COVER PLATE TO BRACKET
155
NUT PUMP TO BRACKET
155
NUT , Replaced By: N913004006001
158
CLAMP OIL-DIPSTICK GUIDE TUBE TO BRACKET
158
CLAMP , Replaced By: A3609951201
161
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
161
SCREW , Replaced By: N304017008016
164
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
164
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
164
NUT , Replaced By: N913004008001
