Поз.
Артикул
Описание
3
CLUTCH PARTS KIT F&S,K 017132
5
CLUTCH PRESSURE PLATE , Replaced By: A0052508404
5
CLUTCH PRESSURE PLATE , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
CLUTCH PRESSURE PLATE , COMPONENT PARTS NOT AVAILABLE PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
8
RELEASE RING REPAIR KIT TO 005 250 83 04
8
RELEASE RING REPAIR KIT TO 004 250 88 04
11
LOCKTO 004 250 88 04, MUST NOT BE EXCHANGED INDIVIDUALLY, USE 000 252 03 46 RANGE OF DELIVERY
14
SPRINGTO 004 250 88 04
16
RELEASE BEARING ,K 017132
16
RELEASE BEARING ,K 017131
16
RELEASE BEARING ,K 017132 FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 097757, Replaced By: A0012509815
16
RELEASE BEARING ,K 017131
16
RELEASE BEARING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0012506415, +001A6502503113, +001A6502540006
16
RELEASE BEARING ,K 017132
20
CLUTCH DISC , Replaced By: A0162503803
20
CLUTCH DISC , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0142506803
20
CLUTCH DISC , Replaced By: A0142506803
20
CLUTCH DISC , Replaced By: A0172504803
23
CLUTCH LINING ASBESTOS-FREE
26
LEAF SPRING ,5 563495
29
RIVET LEAF SPRING TO CLUTCH DISC
32
RIVET LINING WITH CLUTCH DISC
32
RIVET , Replaced By: A0002524875
35
SCREW CLUTCH TO FLYWHEEL
38
BELL HOUSING
38
BELL HOUSING , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 014343, Replaced By: A6552511001
38
BELL HOUSING , Replaced By: A6552510301
44
SCREW VIBRATION ABSORBER TO CONSOLE
47
LOCK WASHER BELL HOUSING TO TRANSMISSION
53
RELEASE LEVER
53
RELEASE LEVER , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO.K 281331, Replaced By: A6502503813
53
RELEASE LEVER , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO.K 048933, Replaced By: A6502503113
53
RELEASE LEVER , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6502501313
56
BEARING TOP
57
ROLLER RELEASE LEVER,K 281332
57
ROLLER
58
PIN RELEASE LEVER,K 281331
59
BUSHING FRONT AND REAR
62
SNAP RING FRONT AND REAR
63
SNAP RING FRONT AND REAR,K 281331
65
SPINDLE
68
PIN RELEASE LEVER
71
SCREW RELEASE LEVER TO BELL HOUSING
89
SCREW RADIATOR M 10X45
92
WASHER RADIATOR TO RUBBER MOUNTING
92
WASHER , Replaced By: N000125010532
