Поз.
Артикул
Описание
5
BALL PIVOT LOAD SENSOR
8
NUT AT FILTER BRACKET
8
NUT PUMP TO BRACKET
8
NUT , Replaced By: N913004006001
11
PULL ROD FROM ACCELERATOR PEDAL TO CONTROL SHAFT BEARING, TO BE ADAPTED DURING ASSEMBLY
11
PULL ROD FROM ACCELERATOR PEDAL TO CONTROL SHAFT BEARING, TO BE ADAPTED DURING ASSEMBLY
11
PULL ROD FROM ACCELERATOR PEDAL TO CONTROL SHAFT BEARING, TO BE ADAPTED DURING ASSEMBLY
14
ROD FROM ACCELERATOR PEDAL TO CONTROL SHAFT BEARING
14
ROD , Replaced By: A6583001715
17
BALL SOCKET PULL ROD TO INTERMEDIATE LEVER
20
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
23
NUT BALL PIVOT TO LEVER
26
NUT L.H. THREAD
29
TURNBUCKLE TURNBUCKLE
32
ROD LOAD SENSOR CONTROL
32
ROD FROM ACCELERATOR PEDAL TO INTERMEDIATE LEVER
32
ROD LOAD SENSOR CONTROL
35
ROD FROM CONTROL SHAFT BEARING TO INTERMEDIATE LEVER
35
ROD LOAD SENSOR CONTROL
38
BALL SOCKET PULL ROD TO LEVER
41
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
44
NUT BALL SOCKET TO ROD
47
PULL ROD FROM CONTROL SHAFT BEARING TO ENGINE SHAFT, TO BE ADAPTED DURING ASSEMBLY
47
PULL ROD FROM CONTROL SHAFT BEARING TO ENGINE SHAFT, TO BE ADAPTED DURING ASSEMBLY
47
PULL ROD FROM ACCELERATOR PEDAL TO INTERMEDIATE LEVER
50
PULL ROD FROM ACCELERATOR PEDAL TO INTERMEDIATE LEVER
50
ROD FROM CONTROL SHAFT BEARING TO ENGINE SHAFT
50
ROD , Replaced By: N900331008421
50
ROD , Replaced By: N900331008421
53
NUT INTERMEDIATE SPEED STOP
56
NUT
56
NUT , Replaced By: N304032008006
59
NUT TURNBUCKLE
62
BALL SOCKET ROD TO BALL PIVOT
65
BALL SOCKET ROD TO BALL PIVOT
68
SECURING CLIP. CIRCLIP
71
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
71
NUT
71
NUT , Replaced By: N304032008006
72
YOKE SHIFTING ROD TO INTERMEDIATE LEVER
74
BRACKET FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
77
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
77
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
80
POWER CYLINDER EXHAUST BRAKE
83
ROD EXHAUST BRAKE
86
BALL SOCKET PULL ROD TO LEVER
89
NUT BALL PIVOT TO LEVER
92
HOLLOW SCREW HEATING CONNECTION
95
SEAL RING LINE CONNECTION
999
COTTER PIN CONNECTOR TO BRAKE PRESSURE REGULATOR LEVER
999
SPRING WASHER , Replaced By: N000137008212
999
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
999
WASHER PULL ROD TO SHIFT LEVER
999
WASHER BRACKET TO CROSS MEMBER
999
PIN ROD TO LEVER
