Поз.
Артикул
Описание
5
VALVE PARKING BRAKE WITH TRAILER CONTROL "KNORR"
5
VALVE PARKING BRAKE WITH TRAILER CONTROL "BOSCH"
5
VALVE PARKING BRAKE WITH TRAILER CONTROL "WABCO", PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
8
HANDLETO 002 430 93 81
11
BUSHING"WABCO"
11
BUSHING , Replaced By: A4421440050
14
BUSHINGTO 002 430 93 81
17
PROTECTIVE CAPTO 002 430 93 81
20
LEVERTO 002 430 93 81
20
LEVER PARKING BRAKE VALVE WABCO
23
SPRING RETAINERTO 002 430 93 81
26
PINTO 002 430 90 81
29
PINTO 002 430 93 81
32
REPAIR KIT HAND BRAKE VALVE "WABCO"
32
REPAIR KITBOSCH,TO 002 430 93 81
35
SCREW PARKING BRAKE VALVE TO WINDOW SILL
38
LOCK WASHER PARKING BRAKE VALVE TO WINDOW SILL
41
GUMMED LABEL PARKING BRAKE ACTUATION
44
BREATHER PIPE PARKING BRAKE VALVE,CONNECTION: "30"
44
BREATHER PIPE PARKING BRAKE VALVE,CONNECTION: "30", Replaced By: A6554310273
45
CLAMP HOSE TO PARKING BRAKE VALVE
47
SCREW. UNION SCREW , Replaced By: A0009973734
47
SCREW. UNION SCREW LINE CONNECTION
50
BRAKE VALVE (TRAILER CONTROL VALVE) "WABCO", PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
50
TRAILER CONTROL VALVE (TRAILER CONTROL VALVE) "KNORR"
50
BRAKE VALVE (TRAILER CONTROL VALVE) "GRAU", PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
50
BRAKE VALVE (TRAILER CONTROL VALVE) "BOSCH"
53
REPAIR KIT TRAILER CONTROL VALVE "WABCO"
53
REPAIR KIT TRAILER CONTROL VALVE "GRAU"
56
BRACKET TRAILER CONTROL VALVE
59
SCREW BRACKET TO CROSS CONNECTION STRUT
59
SCREW , Replaced By: N304017008034
62
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
62
NUT , Replaced By: N913004008001
62
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
65
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
68
SCREW. UNION SCREW LINE CONNECTION
71
SCREW. UNION SCREW LINE CONNECTION
71
SCREW. UNION SCREW , Replaced By: A0009973734
83
SUPPORT TWO-CIRCUIT BRAKE LINE COUPLING
86
ANGLE LEFT
86
ANGLE RIGHT
89
SCREW PIPE CLAMP
89
SCREW , Replaced By: N304017008021
92
WASHER , Replaced By: N000125008443
92
WASHER EXHAUST MUFFLER TO STRAP
95
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
95
NUT , Replaced By: N913004008001
95
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
98
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
98
SCREW , Replaced By: N308676014020
101
NUT , Replaced By: N910113014001
101
NUT BRACKET TO SIDE MEMBER
104
ADAPTER FITTING LINE CONNECTION TO ENGINE
105
ELBOW FITTING CONNECTION OF COMPRESSED AIR LINE 9 MM, M 18X1.5,K 168170
106
ELBOW FITTING CONNECTION OF COMPRESSED AIR LINE 9 MM, M 18X1.5,K 168170
107
NUT BRACKET TO SIDE MEMBER
110
SCREW. UNION SCREW LINE CONNECTION
