Поз.
Артикул
Описание
152
LINE FROM FITTING TO RIGHT DIAPHRAGM CYLINDER
153
CLAMP COMPRSSED AIR LINE TO SUBSTRUCTURE
154
CLIP COMPRSSED AIR LINE TO SUBSTRUCTURE
155
CLAMP 3/2-WAY SOLENOID VALVE
158
SCREW CLAMP TO BRACKET M 6X14
158
SCREW CLAMP TO BRACKET
158
SCREW CLAMP TO BRACKET, Replaced By: N007985006581
161
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
161
WASHER COMPRESSED AIR LINE TO BRACKET
164
NUT PUMP TO BRACKET
164
NUT , Replaced By: N913004006001
167
HOSE FRONT AND REAR AXLE BRAKE CYLINDERS 11 MM
170
FITTING DIAPHRAGM CYLINDER,CONNECTION:
173
UNION NUT LINE CONNECTION, Replaced By: N000000006239
173
UNION NUT LINE CONNECTION
176
SEAL CONE LINE CONNECTION
176
GLAND , Replaced By: A0019901967
179
CLAMP HOSE TO FITTING AND TO OIL TANK
179
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
182
ADAPTER FITTING LINE CONNECTION TO ENGINE
185
NUT BRACKET TO SIDE MEMBER
191
T-FITTING LEFT AND RIGHT BRAKE HOSES
194
T-FITTING DIAPHRAGM CYLINDER
197
SCREW. UNION SCREW LINE CONNECTION
200
FITTING DELIVERY LINE TO PUMP
203
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
206
ELBOW FITTING TRAILER CONTROL VALVE,CONNECTION: 1.1
209
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
212
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
215
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
218
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
218
TEST CONNECTION BULKHEAD FITTING
218
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
218
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
218
TEST CONNECTION
221
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
224
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
227
REPAIR KIT. TS SEALING RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
