Поз.
Артикул
Описание
23
PLATE , Replaced By: A6573200435
23
PLATE AIR SPRING BELLOWS,TOP
23
PLATE AIR SPRING BELLOWS,TOP LEFT
23
PLATE AIR SPRING BELLOWS,TOP RIGHT
23
PLATE AIR SPRING BELLOWS,TOP
23
PLATE AT FRAME
26
PLATE AIR SPRING BELLOWS,TOP
26
PLATE AIR SPRING BELLOWS,TOP RIGHT
26
PLATE AIR SPRING BELLOWS,TOP LEFT
29
SCREW SUPPORT TO SIDE MEMBER M 14X45
29
SCREW , Replaced By: N308676014012
29
SCREW APPARATUS SUPPORT TO FRAME
29
SCREW , Replaced By: A9429901304
29
SCREW LEFT AND RIGHT CONSOLES TO CAB
29
SCREW , Replaced By: N308676012015
29
SCREW BRACKET TO FRAME M 12X35
35
NUT STEERING SUPPORT TO FRAME
35
NUT , Replaced By: N910113014000
35
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
35
NUT , Replaced By: N910113012003
41
AIR SPRING BELLOWS PNEUMATIC SUSPENSION
41
AIR SPRING BELLOWS FRONT AXLE II PNEUMATIC SUSPENSION
41
AIR SPRING BELLOWS PNEUMATIC SUSPENSION
43
SEAL RING FRONT AXLE II PNEUMATIC SUSPENSION
45
RING FRONT AXLE II PNEUMATIC SUSPENSION
47
RUBBER BUFFER (RUBBER STOP),EMERGENCY RUNNING,K 017385
53
PISTON TRAILING AXLE
53
PISTON STEERED AXLE PNEUMATIC SUSPENSION
53
PISTON PNEUMATIC SUSPENSION
53
PISTON FRONT AXLE II PNEUMATIC SUSPENSION
56
SHIM PISTON TO AIR-SPRING-BELLOWS SUPPORT
56
SHIM PISTON TO FRONT AXLE II AIR-SPRING BELLOWS SUPPORT
59
SCREW TORSION BAR TO BEARING BRACKET M 16X115,5 903514
59
SCREW PISTON TO FRONT AXLE II AIR-SPRING BELLOWS SUPPORT M 16X150
59
SCREW SHACKLE TO CONSOLE
59
SCREW AT ENGINE MOUNTING,TO MOUNT LINES
59
SCREW PISTON TO FRONT AXLE II AIR-SPRING BELLOWS SUPPORT
62
WASHER ,4 179002-4 369654
228
SHOCK ABSORBER REAR AXLE
228
SHOCK ABSORBER STEERED AXLE
234
RUBBER MOUNTINGTO 002 323 86 00,003 323 03 00,
234
RUBBER BUFFER , Replaced By: A0003233144
234
RUBBER BUFFER SHOCK ABSORBER,BOTTOM TO 003 326 45 00, Replaced By: A0003238085
234
RUBBER MOUNTINGTO 003 326 46 00
240
SPACER RINGTO 002 323 86 00,003 323 03 00,
240
BUSHINGTO 003 326 48 00
243
WASHER HYDRAULIC CYLINDER TO CAB
246
SCREW SHOCK ABSORBER TO TOP BRACKET M 16X125
246
SCREW SHOCK ABSORBER TO CONSOLE,TOP
246
SCREW RUBBER MOUNTING TO SUPPORTING ARM M16X80,5 566418
249
WASHER SHOCK ABSORBER TO LOWER BEARING BRACKET
252
SCREW BRACKET TO AIR INTAKE SCOOP
258
NUT CONSOLE TO SUPPORT
258
NUT , Replaced By: N910113016001
258
NUT COMBINATION CYLINDER TO BEARING BRACKET
258
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
264
BRACKET RIGHT
264
BRACKET RIGHT
264
BRACKET LEFT
264
BRACKET LEFT
264
BRACKET SHOCK ABSORBER,TOP
267
BRACKET SHOCK ABSORBER,TOP
270
SCREW ENGINE TO ENGINE FRONT SUPPORT
270
SCREW TRAILER COUPLING TO REAR CROSS MEMBER
270
SCREW APPARATUS SUPPORT TO FRAME
270
SCREW , Replaced By: A9429901304
270
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
270
SCREW , Replaced By: N308676012026
276
NUT STEERING SUPPORT TO FRAME
276
NUT , Replaced By: N910113014000
276
NUT COMBINATION CYLINDER TO BEARING BRACKET
276
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
276
NUT SUPPORT TO SIDE MEMBER
279
BRACKET AIR SPRING VALVE
282
LEVER AIR SPRING VALVE
285
BALL PIVOT BOTTOM B13X5 MM
288
PULL ROD FROM INTERMEDIATE LEVER TO ENGINE, TO BE ADAPTED DURING ASSEMBLY
291
YOKE TOP
294
NUT INTERMEDIATE SPEED STOP
297
SECURING CLIP. CIRCLIP
297
BALL SOCKET ROD TO BALL PIVOT
300
NUT
300
NUT , Replaced By: N304032008006
