Поз.
Артикул
Описание
5
PLASTIC PIPE AERATION, ORDER BY THE METER
5
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
8
FITTING (PARTS KIT),LINE RUPTURE
11
LOOM TIE LINE MOUNTING 280 MM
14
HOLLOW SCREW FUEL LINE TO FEED PUMP
14
HOLLOW SCREW FUEL LINE TO FEED PUMP
14
HOLLOW SCREW , Replaced By: N915036010108
17
SEAL RING FUEL LINE TO FEED PUMP
17
SEAL RING FUEL LINE TO FEED PUMP
20
CLAMP LEAK LINE TO CONNECTOR AT ENGINE
23
GROMMET FUEL LINE THRU FRAME SIDE MEMBER
23
GROMMET FUEL LINE THRU FRAME SIDE MEMBER
23
GROMMET FUEL LINE THRU FRAME SIDE MEMBER
23
GROMMET FOR PASSAGE OF LINE
23
GROMMET FUEL LINE THRU FRAME SIDE MEMBER
23
GROMMET FUEL LINE THRU FRAME SIDE MEMBER 38/30 MM
26
HOSE CLAMP FUEL LINE TO SENDER UNIT
29
BRACKET AT FRAME
32
BRACKET FUEL LINE TO BELL HOUSING
32
BRACKET AT ENGINE
32
BRACKET , Replaced By: A6504700481
35
BRACKET FUEL LINE TO FRAME
35
BRACKET FUEL LINE TO BELL HOUSING
35
BRACKET FUEL LINE TO BELL HOUSING
38
PLATE CABLE HARNESS MOUNTING
38
BRACKET FUEL LINE TO BELL HOUSING
41
PROTECTIVE PLATE FUEL LINE TO BELL HOUSING
44
LOOM TIE LINE MOUNTING
