Поз.
Артикул
Описание
5
VALVE PARKING BRAKE WITH TRAILER CONTROL "KNORR"
5
VALVE PARKING BRAKE WITH TRAILER CONTROL "BOSCH"
5
VALVE PARKING BRAKE WITH TRAILER CONTROL "WABCO", PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
8
HANDLETO 002 430 93 81
11
BUSHINGTO 002 430 93 81
11
BUSHING"WABCO"
11
BUSHING , Replaced By: A4421440050
14
PROTECTIVE CAPTO 002 430 93 81
14
PROTECTIVE CAP PARKING BRAKE VALVE WABCO
17
LEVERTO 002 430 93 81
17
LEVER PARKING BRAKE VALVE WABCO
20
SPRING RETAINERTO 002 430 93 81
23
PINTO 002 430 93 81
23
PINTO 002 430 90 81
26
REPAIR KITBOSCH,TO 002 430 93 81
26
REPAIR KIT HAND BRAKE VALVE "WABCO"
29
SCREW PARKING BRAKE VALVE TO WINDOW SILL
32
LOCK WASHER PARKING BRAKE VALVE TO WINDOW SILL
35
GUMMED LABEL PARKING BRAKE ACTUATION
38
BREATHER PIPE PARKING BRAKE VALVE,CONNECTION: "30"
38
BREATHER PIPE PARKING BRAKE VALVE,CONNECTION: "30", Replaced By: A6554310273
41
SCREW. UNION SCREW LINE CONNECTION
41
SCREW. UNION SCREW , Replaced By: A0009973734
42
CLAMP HOSE TO PARKING BRAKE VALVE
44
TRAILER CONTROL VALVE (TRAILER CONTROL VALVE) "KNORR"
44
BRAKE VALVE (TRAILER CONTROL VALVE) "GRAU", PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
44
BRAKE VALVE (TRAILER CONTROL VALVE) "BOSCH"
44
BRAKE VALVE (TRAILER CONTROL VALVE) "WABCO", PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
44
BRAKE VALVE , Replaced By: A0034318205
47
REPAIR KIT TRAILER CONTROL VALVE "GRAU"
47
REPAIR KIT TRAILER CONTROL VALVE "WABCO"
50
BRACKET TRAILER CONTROL VALVE,K 213085
53
SCREW SUPPORT TO FENDER
53
SCREW , Replaced By: N304017008018
56
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
56
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
56
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
56
NUT , Replaced By: N913004008001
59
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
62
SCREW. UNION SCREW LINE CONNECTION
65
SCREW. UNION SCREW LINE CONNECTION
65
SCREW. UNION SCREW , Replaced By: A0009973734
68
SUPPORT TWO-CIRCUIT BRAKE LINE COUPLING
74
ANGLE RIGHT
74
ANGLE LEFT
74
ANGLE , Replaced By: A6214320017
77
SCREW PIPE CLAMP
77
SCREW , Replaced By: N304017008021
80
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
80
SCREW , Replaced By: N308676014020
83
WASHER EXHAUST MUFFLER TO STRAP
83
WASHER , Replaced By: N000125008443
86
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
86
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
86
NUT , Replaced By: N913004008001
89
NUT BRACKET TO SIDE MEMBER
89
NUT , Replaced By: N910113014001
90
ADAPTER FITTING TEST CONNECTION
92
ADAPTER FITTING LINE CONNECTION TO ENGINE
93
ELBOW FITTING CONNECTION OF COMPRESSED AIR LINE 9 MM, M 18X1.5,K 168170
94
ELBOW FITTING CONNECTION OF COMPRESSED AIR LINE 9 MM, M 18X1.5,K 168170
95
NUT BRACKET TO SIDE MEMBER
98
SCREW. UNION SCREW LINE CONNECTION
101
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
104
LOCK RING LINE CONNECTION
104
SEAL RING , Replaced By: A0009940747
107
LOCK LINE CONNECTION
107
LOCK , Replaced By: A0009945448
110
SCREW. UNION SCREW LINE CONNECTION
110
SCREW. UNION SCREW , Replaced By: A0009973734
999
HANDLE"WABCO"
