Поз.
Артикул
Описание
5
RADIATOR , Replaced By: A6525012501
5
RADIATOR WATER
5
RADIATOR , Replaced By: A6525014201
5
RADIATOR , Replaced By: A6525014201
5
RADIATOR , FROM IDENT NO. 5 623090, SEE STANDARD MICROFICHE, Replaced By: A6525016601, +001A6552602262, +001A6552602985, +001A6552603085, +001A6559974182, +001A6559974682
5
RADIATOR , FROM IDENT NO. 5 623090, SEE STANDARD MICROFICHE, Replaced By: A6525016601, +001A6552602262, +001A6552602985, +001A6552603085, +001A6559974182, +001A6559974682
5
RADIATOR WITH SCREW FITTING
5
RADIATOR
5
RADIATOR , Replaced By: A6525014901
5
RADIATOR ,K 115007
5
RADIATOR ,K 115007
5
RADIATOR , Replaced By: A6525016901
5
RADIATOR WITH SCREW FITTING,K 115008
6
SCREW , Replaced By: A0005000085
6
SCREW WATER DRAIN
8
GASKET COOLING WATER DRAIN TO 656 500 00 03
9
LOCK
17
RUBBER MOUNTING RADIATOR
20
SCREW , Replaced By: N304017010028
20
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
20
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
23
WASHER , Replaced By: N000125010532
23
WASHER RADIATOR TO RUBBER MOUNTING
26
FAN SHROUD RADIATOR
26
FAN SHROUD
29
DETENT FAN SHROUD TO RADIATOR
30
LOCK , Replaced By: N912002008003
30
LOCK PULL TO FASTENER
35
BOOT FAN SHROUD TO FAN RING
35
BOOT , Replaced By: A6565050286
35
BOOT FAN SHROUD TO FAN RING
43
TANK COOLING WATER EXPANSION
44
RADIATOR CAP , Replaced By: A0005016415
44
RADIATOR CAP FILLER NECK
45
SEAL RING
47
RADIATOR CAP
50
RADIATOR CAP CENTRAL
50
RADIATOR CAP CENTRAL
53
GASKET O.D., 52 MM
56
GASKET O.D., 37 MM
59
DRAIN PIPE
62
SENDER UNIT COOLING WATER LEVEL INDICATOR
65
PLATE FROM EXPANSION TANK TO RADIATOR 40X40 MM
65
PLATE FROM EXPANSION TANK TO RADIATOR
68
BRACKET. LOCK , Replaced By: A6525040038
68
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
71
HOSE FROM EXPANSION TANK TO ENGINE
74
CLAMP , Replaced By: N916017011001
74
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
113
BRACKET , NOT USED
146
SCREW , Replaced By: N304017006016
146
SCREW PUMP TO BRACKET
149
NUT , Replaced By: A0009902291
149
NUT RETAINER , Replaced By: A0019906791
149
NUT RETAINER LICENSE PLATE TO BRACKET
152
SCREW , Replaced By: A6739900032
152
SCREW DE-AERATION LINE TO RADIATOR
999
NUT , Replaced By: N913004008001
999
SCREW , Replaced By: N304017008016
