Поз.
Артикул
Описание
5
CONNECTOR (CONNECTING PIPE),RIGHT FRONT
5
CONNECTOR (CONNECTING PIPE),RIGHT FRONT
5
CONNECTOR (CONNECTING PIPE),LEFT FRONT
5
CONNECTOR LEFT EXHAUST PIPE
8
SCREW CONNECTING PIPE TO EXHAUST MANIFOLD M 12X45
11
NUT CONNECTOR TO EXHAUST MANIFOLD
14
FLEXIBLE METAL TUBE FRONT EXHAUST PIPE FRONT PART TO REAR PART
17
COLLAR FRONT EXHAUST PIPE FRONT PART TO REAR PART
20
CLAMP FLEXIBLE METAL TUBE TO EXHAUST PIPE
23
SCREW , Replaced By: N304017008018
23
SCREW SUPPORT TO FENDER
26
NUT , Replaced By: N913004008001
26
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
26
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
29
EXHAUST PIPE FRONT,REAR LEFT PART
29
EXHAUST PIPE FRONT,REAR LEFT PART
32
EXHAUST PIPE FRONT,REAR RIGHT PART
32
EXHAUST PIPE FRONT,REAR RIGHT PART
35
BRACKET FRONT EXHAUST PIPE
35
BRACKET LEFT EXHAUST PIPE
38
BRACKET RIGHT EXHAUST PIPE
38
BRACKET FRONT EXHAUST PIPE TO SIDE MEMBER
41
SCREW END PIECE TO EXHAUST PIPE M 10X25
41
SCREW , Replaced By: N304017010002
41
SCREW BRACKET TO SIDE MEMBER
44
NUT , Replaced By: N910113010000
44
NUT STRAP TO BRACKET
47
CLAMP AT CROSS MEMBER
50
SCREW BRACKET TO SIDE MEMBER
50
SCREW , Replaced By: N304017010002
53
NUT STRAP TO BRACKET
53
NUT , Replaced By: N910113010000
56
CLAMP PROTECTIVE PLATE TO EXHAUST PIPE
56
CLAMP , Replaced By: N071555094502
59
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
59
SCREW , Replaced By: N304017008027
62
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
62
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
62
NUT , Replaced By: N913004008001
65
EXHAUST MUFFLER LEFT AND RIGHT
