Поз.
Артикул
Описание
5
PUMP , Replaced By: A0005537901, +001A0015534205
5
PUMP (HAND PUMP) WEBER
8
PISTONTO 000 553 79 01,WEBER
11
VALVETO 000 553 79 01,WEBER
14
FILTERHUNGER
14
FILTER
17
FITTED WASHER
20
LOCK RING
23
SCREW OIL FILLING HUNGER
23
SCREW
26
SCREW BOX COVER TO 000 553 79 01,000 553 89 01
26
SCREW , Replaced By: N000912008201
26
SCREW
26
SCREW , Replaced By: N000000000190
29
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
32
GASKETHUNGER
35
GASKET KIT HAND PUMP TO 000 553 68 01
35
GASKET KIT HAND PUMP
38
PLATE HAND PUMP
44
BRACKET , Replaced By: A6225500040
47
SCREW EXHAUST PIPE TO BRACKET
47
SCREW BRACKET TO SIDE MEMBER
47
SCREW , Replaced By: N304017010002
47
SCREW REAR EXHAUST PIPE TO MUFFLER
50
NUT STRAP TO BRACKET
50
NUT , Replaced By: N910113010000
53
SCREW BRACKET TO SIDE MEMBER
104
CYLINDER HYDRAULIC SYSTEM USED FOR CAB TILTING HUNGER
104
CYLINDER HYDRAULIC SYSTEM USED FOR CAB TILTING WEBER
105
GUIDEWEBER,TO 001 553 45 05
107
GASKET KIT HYDRAULIC CYLINDER POWER PACKER
110
BEARING BRACKET HYDRAULIC CYLINDER
110
BEARING BRACKET , Replaced By: A6555530238
113
SCREW BEARING BRACKET TO REAR AXLE M 16X1.5X40
113
SCREW HYDRAULIC CYLINDER BEARING BRACKET TO FRAME M 16X25
119
BUSHING HYDRAULIC CYLINDER TO BEARING BRACKET
122
WASHER HYDRAULIC CYLINDER TO CAB
125
COTTER PIN6,3X36 MM
134
WASHER HYDRAULIC CYLINDER TO CAB
146
NUT LEVER TO SUPPORT
146
NUT LEVER
146
NUT , Replaced By: N000979016008
149
COTTER PIN STRAP TO SUPPORT
