Поз.
Артикул
Описание
5
GROMMET LINE PASSAGE AT SIDE MEMBER 32/27 MM
8
WASHER BRACKET TO LEFT SIDE MEMBER
11
BRACKET LEFT COMPRESSED AIR LINES, Replaced By: A6554303310
11
BRACKET LEFT COMPRESSED AIR LINES
11
BRACKET RIGHT COMPRESSED AIR LINES, Replaced By: A6554303410
11
BRACKET RIGHT COMPRESSED AIR LINES
14
BRACKET TWIN OIL FILTER FLANGE,FRONT
17
SCREW , Replaced By: N304017008021
17
SCREW PIPE CLAMP
20
NUT , Replaced By: N913004008001
20
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
20
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
21
WASHER , Replaced By: N000125008443
21
WASHER EXHAUST MUFFLER TO STRAP
23
BRACKET ACCORDION TUBE
23
BRACKET ACCORDION TUBE
24
BRACKET BRACKET TO BRACKET,K 012508
24
BRACKET BRACKET TO BRACKET,K 012508
26
SCREW END PIECE TO EXHAUST PIPE M 12X30
26
SCREW , Replaced By: N304017012020
29
NUT END PIECE TO EXHAUST PIPE
32
BRACKET BREATHER LINE TO SIDE MEMBER
35
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
35
SCREW , Replaced By: N304017008027
36
SCREW BRACKET TO SIDE MEMBER
37
SCREW BRACKET TO SIDE MEMBER
37
SCREW , Replaced By: N304017010002
37
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
37
SCREW , Replaced By: N308676012012
38
LOCK WASHER FITTING TO BRACKET
39
NUT STRAP TO BRACKET
39
NUT , Replaced By: N910113010000
39
NUT GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
39
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
39
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
39
NUT , Replaced By: N913004008001
41
BRACKET COMPRESSED AIR LINE TO SIDE MEMBER
42
BRACKET FRONT CROSS MEMBER
43
BRACKET LEFT SIDE MEMBER,FRONT
44
BRACKET LINE TO FRONT PANEL, FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 115008, Replaced By: A0002930040
44
BRACKET LINE TO FRONT PANEL, FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 115008, Replaced By: A0002930040
45
BRACKET LINE TO FRONT PANEL
46
EDGE GUARD SECTION AT SHOCK ABSORBER BRACKET, ORDER BY THE METER
46
EDGE GUARD SECTION , Replaced By: A0019872272
47
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
47
WASHER , Replaced By: N009021005205
48
NUT BRACKET TO PIN
53
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
53
SCREW , Replaced By: N304017008027
56
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
56
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
56
NUT , Replaced By: N913004008001
65
NUT
73
BRACKET BRACKET TO CONTROL ARM
74
SHEET METAL SCREW ELECTRIC CABLE TO CABLE DUCT
84
CLAMP COMPRSSED AIR LINE TO SUBSTRUCTURE
85
CLIP COMPRSSED AIR LINE TO SUBSTRUCTURE
