Поз.
Артикул
Описание
5
RADIATOR , FROM IDENT NO. 5 623090, SEE STANDARD MICROFICHE, Replaced By: A6525016601, +001A6552602262, +001A6552602985, +001A6552603085, +001A6559974182, +001A6559974682
5
RADIATOR WITH SCREW FITTING
5
RADIATOR , Replaced By: A6525014201
5
RADIATOR , Replaced By: A6525014201
8
SCREW , Replaced By: A0005000085
8
SCREW WATER DRAIN
11
GASKET COOLING WATER DRAIN TO 656 500 00 03
14
LOCK
17
RUBBER MOUNTING RADIATOR
20
SCREW BRACKET TO APPARATUS SUPPORT M 10X30
23
WASHER RADIATOR TO RUBBER MOUNTING
23
WASHER , Replaced By: N000125010532
26
FAN SHROUD RADIATOR
29
DETENT FAN SHROUD TO RADIATOR
32
LOCK PULL TO FASTENER
32
LOCK , Replaced By: N912002008003
35
BOOT FAN SHROUD TO FAN RING
36
BOOT (SEALING LIP)
37
BRACKET SEALING LIP TO RADIATOR
38
BRACKET SEALING LIP TO OIL DIPSTICK BRACKET
38
BRACKET SEALING LIP TO OIL DIPSTICK BRACKET
39
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
40
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
40
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
41
BRACKET SEALING LIP TO EXPANSION TANK
42
PIN SEALING LIP TO EXPANSION TANK
43
TANK COOLING WATER EXPANSION
44
RADIATOR CAP , Replaced By: A0005016415
44
RADIATOR CAP FILLER NECK
45
SEAL RING
47
RADIATOR CAP
50
RADIATOR CAP CENTRAL
50
RADIATOR CAP CENTRAL
53
GASKET O.D., 52 MM
56
GASKET O.D., 37 MM
59
DRAIN PIPE
62
SENDER UNIT COOLING WATER LEVEL INDICATOR
65
PLATE FROM EXPANSION TANK TO RADIATOR
65
PLATE FROM EXPANSION TANK TO RADIATOR 40X40 MM
68
BRACKET. LOCK , Replaced By: A6525040038
68
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
71
HOSE FROM EXPANSION TANK TO ENGINE
74
CLAMP , Replaced By: N916017011001
74
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
110
SCREW DE-AERATION LINE TO RADIATOR
113
BRACKET OIL DIPSTICK GUIDE TUBE
119
BRACKET OIL DIPSTICK GUIDE TUBE
122
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
122
SCREW PUMP TO BRACKET
122
SCREW , Replaced By: N304017006016
122
SCREW , Replaced By: N304017008016
125
NUT PUMP TO BRACKET
128
CLAMP OIL-DIPSTICK GUIDE TUBE TO BRACKET
131
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
131
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
131
NUT , Replaced By: N913004008001
999
SCREW , Replaced By: N304017008016
999
NUT , Replaced By: N913004008001
