Поз.
Артикул
Описание
8
PUMP (HAND PUMP) WEBER
8
PUMP (HAND PUMP) POWER PACKER,4 733732
8
PUMP (HAND PUMP), FOR COMPONENT PARTS SEE SPARE PARTS LIST
8
PUMP (HAND PUMP) POWER PACKER
8
PUMP , Replaced By: A0005537901, +001A0015534205
8
PUMP (HAND PUMP), FOR COMPONENT PARTS SEE SPARE PARTS LIST
64
SCREW , Replaced By: N000912008201
64
SCREW , Replaced By: N000000000190
64
SCREW BOX COVER TO 000 553 79 01,000 553 89 01
64
SCREW
72
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
80
GASKETHUNGER
88
FILTER
90
FILTERHUNGER
96
VALVEWEBER,TO 000 553 89 01
96
VALVETO 000 553 79 01,WEBER
96
VALVETO 000 553 88 01
96
VALVEWEBER,TO 000 553 40 01
96
VALVETO 000 553 89 01
128
PISTON , Replaced By: A0005531990
128
PISTONWEBER,TO 000 553 40 01
128
PISTONTO 000 553 89 01
128
PISTONTO 000 553 79 01,WEBER
152
LOCK RING
160
FITTED WASHER
192
SCREW OIL FILLING TO 000 553 89 01
192
SCREW
192
SCREW OIL FILLING HUNGER
192
PART NAME MISSING OIL FILLING WEBER
194
SCREWTO 000 553 65 01,000 553 69 01,
196
REPAIR KIT HAND PUMP TO 000 553 65 01,000 553 69 01,
198
GASKET KIT HAND PUMP
198
GASKET KIT HAND PUMP TO 000 553 37 01,000 553 39 01,WEBER
198
GASKET KIT HAND PUMP TO 000 553 68 01
208
SCREW REAR EXHAUST PIPE TO MUFFLER
208
SCREW END PIECE TO EXHAUST PIPE M 10X25
208
SCREW BRACKET TO SIDE MEMBER
208
SCREW , Replaced By: N304017010002
208
SCREW EXHAUST PIPE TO BRACKET
240
NUT STRAP TO BRACKET
240
NUT , Replaced By: N910113010000
242
BRACKET , Replaced By: A6525530240
242
BRACKET HAND PUMP
242
BRACKET HAND PUMP,5 942826
242
BRACKET HAND PUMP
242
BRACKET HAND PUMP
248
BRACKET AIR CLEANER SUPPORT
248
BRACKET , Replaced By: A6225500040
250
BRACKET HAND PUMP
252
SCREW BRACKET TO SIDE MEMBER
252
SCREW REAR EXHAUST PIPE TO MUFFLER
252
SCREW END PIECE TO EXHAUST PIPE M 10X25
253
SCREW , Replaced By: N308676012026
253
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
254
NUT SUPPORT TO SIDE MEMBER
255
SCREW , Replaced By: N308676014020
255
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
255
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
258
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
258
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
258
SCREW , Replaced By: N308676014020
260
NUT , Replaced By: N910113014001
260
NUT BRACKET TO SIDE MEMBER
262
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
263
NUT BRACKET TO SIDE MEMBER
263
NUT , Replaced By: N910113014001
340
CLAMP LINE MOUNTING
341
SCREW PUMP TO BRACKET
341
SCREW , Replaced By: N304017006016
342
NUT , Replaced By: N913004006001
342
NUT PUMP TO BRACKET
470
LINE FROM FITTING TO VALVE 6X1 MM, LENGTH AVAILABLE 3000 MM
470
LINE FROM HAND PUMP TO HIGH PRESSURE HOSE
470
LINE FROM HAND PUMP TO HIGH PRESSURE HOSE
475
UNION NUT
480
SEAL CONE
480
GLAND , Replaced By: A0019901667
485
ANGLE LINE MOUNTING
490
BRACKET SUCTION LINE
495
CLAMP LINE MOUNTING
500
SCREW CLAMP TO BRACKET, Replaced By: N007985006581
500
SCREW CLAMP TO BRACKET
505
SCREW , Replaced By: N304017008027
505
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
510
NUT , Replaced By: N913004006001
510
NUT PUMP TO BRACKET
536
CONNECTION FITTING , Replaced By: A0039979172
999
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
999
NUT , Replaced By: N910113010000
999
NUT , Replaced By: N913004008001
999
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
NUT COMBINATION CYLINDER TO BEARING BRACKET
999
SCREW BRACKET TO SIDE MEMBER
999
SCREW BRACKET TO CROSS CONNECTION STRUT
999
SCREW , Replaced By: N304017008040
999
SCREW , Replaced By: N304017008034
999
FITTING FROM PUMP TO CYLINDER
999
GROMMET HIGH PRESSURE HOSE THRU FRAME
999
HOSE , Replaced By: A6255531382
999
HOSE FROM HAND PUMP TO HYDRAULIC CYLINDER
999
BRACKET HAND PUMP
999
GROMMET HIGH PRESSURE HOSE THRU FRAME
999
PIN HYDRAULIC CYLINDER TO ROCKER ARM
999
BRACKET HAND PUMP
999
WASHER HYDRAULIC CYLINDER TO CAB
999
WASHER HYDRAULIC CYLINDER TO CAB
999
BRACKET HIGH PRESSURE HOSE
999
CYLINDER HYDRAULIC SYSTEM USED FOR CAB TILTING POWER PACKER
999
ELBOW FITTING FROM PUMP TO CYLINDER, Replaced By: N000000006197
999
CYLINDER HYDRAULIC SYSTEM USED FOR CAB TILTING WEBER
999
PUMP (HAND PUMP)
