Поз.
Артикул
Описание
12
HOSE12030 MM
57
SENDER UNIT FRONT AXLE
57
SENDER UNIT FRONT AXLE
58
BRACKET FRONT AXLE TRAVEL SENSOR
58
BRACKET REAR AXLE
58
BRACKET VALVE BRACKET
59
BRACKET REAR AXLE
60
SCREW ANGLE TO CROSS MEMBER M 10X30
61
NUT GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
62
LEVER FRONT AXLE TRAVEL SENSOR
62
LEVER REAR AXLE
64
VALVE (SOLENOID VALVE)
66
SWITCH , Replaced By: A6935457609
66
SWITCH PARKING BRAKE VALVE,CONNECTION: "11"
200
LINE FROM FITTING TO FITTING
205
VALVE VALVE CLUSTER
205
VALVE VALVE CLUSTER
206
ANTI-FREEZE DEVICE. REPAIR KIT AIR DEHYDRATOR TO 693 420 73 71
206
ANTI-FREEZE DEVICE. REPAIR KIT VALVE TO 693 420 73 71
206
REPAIR KIT PRESSURE REGULATOR TO 693 420 73 71
208
SCREW PLUG SECONDARY CONSUMING UNIT AIR RESERVOIR
210
T-FITTING RIGHT COMBINATION CYLINDER,CONNECTION: "11"
211
O-RING CHECK VALVE TO AIR RESERVOIR
214
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
214
THRUST RING CHECK VALVE TO AIR RESERVOIR
215
UNION NUT
217
ADAPTER FITTING TEST CONNECTION
220
GLAND , Replaced By: A0019901667
221
NUT ,D 091466
223
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
223
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
225
SWITCH PRESSURE SWITCH
226
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
229
SCREW. UNION SCREW , Replaced By: A0009973734
230
ELBOW FITTING HOSE WIDTH, 9 MM,TO M 22
235
BRACKET LINE MOUNTING
999
CONNECTOR HOSE WIDTH, 9 MM,TO M 22
