Поз.
Артикул
Описание
5
AIR CLEANER
5
AIR CLEANER COMPRESSED AIR LINE
8
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
11
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
14
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
17
HOLLOW SCREW LINE TO OIL RADIATOR
17
HOLLOW SCREW BRAKE POWER REGULATOR W/RELAY VALVE, CONNECTION: "40"
20
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
23
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) WABCO
23
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) KNORR
26
REPAIR KITTO 001 431 30 06
26
REPAIR KITTO 002 431 01 06
26
REPAIR KIT FOUR-CIRCUIT PROTECTIVE VALVE
29
FITTING SHUTTLE VALVE,CONNECTION: "20"
29
FITTING , Replaced By: A0019972372
32
NUT AIR RESERVOIR,CONNECTIONS: "14,21,35"
35
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
38
O-RING CHECK VALVE TO AIR RESERVOIR
41
SCREW-IN FITTING OIL LINE CONNECTION
41
FITTING DELIVERY LINE TO PUMP
44
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
47
HOLLOW SCREW FITTING LOCKING VALVE,CONNECTION: "12"
50
FITTING LOCKING VALVE
53
FITTING VALVE TO VALVE
59
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
59
THRUST RING LOCKING VALVE
62
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
65
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
68
VALVE (CHECK VALVE)
68
NON-RETURN VALVE. VALVE WITH CHECK VALVE WABCO,5 433388
68
VALVE (CHECK VALVE)
68
VALVE (CHECK VALVE)
71
REPAIR KIT CHECK TO 003 429 07 44
74
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
77
HOLLOW SCREW FITTING FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION "23"
78
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
80
T-FITTING FROM FOUR-CIRCUIT PROTECTIVE VALVE CONNECTION "23" TO T-FITTING
83
HOLLOW SCREW
83
HOLLOW SCREW
86
HOLLOW SCREW LINE TO OIL RADIATOR
86
HOLLOW SCREW BRAKE POWER REGULATOR W/RELAY VALVE, CONNECTION: "40"
87
HOLLOW SCREW FUEL LINE TO FUEL TANK
89
SEAL RING FUEL LINE TO FEED PUMP
92
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
95
FITTING TWO-WAY VALVE,CONNECTION: "12",4 691316
95
FITTING , Replaced By: A0009970171
98
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
101
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
104
FITTING BRAKE LINE COUPLING,796308
107
CONNECTOR COMPRESSED AIR LINE TO DISTRIBUTOR
107
CONNECTOR , Replaced By: A0039971272, +001A0019901967, +001N915017012100
110
NUT BRACKET TO SIDE MEMBER
