Поз.
Артикул
Описание
5
RESERVOIR , Replaced By: A0034320201
8
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
11
SCREW PLUG SECONDARY CONSUMING UNIT AIR RESERVOIR
14
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
17
HOLLOW SCREW LINE CONNECTION TO TRANSMISSION
17
HOLLOW SCREW FUEL FEED,AT WATER SEPARATOR
20
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
23
FITTING , Replaced By: A0009907771
23
ELBOW FITTING AIR RESERVOIR,CONNECTIONS: "31,32"
26
O-RING CHECK VALVE TO AIR RESERVOIR
29
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
32
NUT AIR RESERVOIR,CONNECTIONS: "14,21,35"
35
RESERVOIR , Replaced By: A0034321201
38
RESERVOIRV 3
41
ELBOW FITTING TWO-WAY VALVE,CONNECTION "1.2"
41
ELBOW FITTING AT BRAKE BOOSTER, B03543/06/08 FROM IDENT NO.: 549430
44
NUT AIR RESERVOIR,CONNECTIONS: "14,21,35"
47
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
50
O-RING CHECK VALVE TO AIR RESERVOIR
53
HOLLOW SCREW FITTING FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION "23"
56
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
59
ELBOW FITTING
59
ELBOW FITTING AIR RESERVOIR,CONNECTION: "15"
62
SCREW AIR RESERVOIR
65
NUT AIR RESERVOIR,CONNECTIONS: "14,21,35"
68
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
71
O-RING CHECK VALVE TO AIR RESERVOIR
74
VALVE
74
VALVE. DRAIN VALVE DRAIN
74
VALVE DRAIN, Replaced By: A0004322107
74
VALVE DRAIN, Replaced By: A0004322407
74
VALVE
77
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
80
FITTING AIR RESERVOIR CONNECTION
83
SEAL RING LINE CONNECTION
89
VALVE DRAIN, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
92
REPAIR KIT DRAIN VALVE
95
HOLLOW SCREW LEFT DISTRIBUTOR,CONNECTION: "70"
95
HOLLOW SCREW LINE CONNECTIONS,4 188090
98
SEAL RING LINE CONNECTION
101
SCREW STEERING SHAFT BEARING TO CAB M 8X20
104
NUT BRACKET TO SIDE MEMBER
