Поз.
Артикул
Описание
5
BRAKE VALVE TWO-CIRCUIT BRAKE WABCO
6
BRAKE VALVEWABCO
8
RS BRAKE VALVE , BIS VENTIL-FERTIGUNG KW 20/01 (SIEHE TYPSCHILD BREMSVENTIL)
8
RS BRAKE VALVE REPAIR KIT, AB VENTIL-FERTIGUNG KW 21/01 (SIEHE TYPSCHILD BREMSVENTIL)
14
SCREWTO 376 131 74 01
17
WASHER PUMP TO CONSOLE
20
NUT HORN TO BRACKET M8
20
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
35
SCREW. UNION SCREW LINE CONNECTION
36
FITTING CHECK VALVE
38
MUFFLER TRAILER CONTROL VALVE
39
HOSE PRESSURE REGULATOR,CONNECTION: "3"
40
CLAMP20 - 32 MM
41
VALVE (RELAY VALVE) WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
41
VALVE FRONT AXLE II RELAY VALVE "WABCO"
44
REPAIR KIT RELAY VALVE TO 004 429 38 44,WABCO
47
WASHER BRACKET TO LEFT SIDE MEMBER
47
WASHER BRACKET TO SIDE MEMBER
50
NUT HORN TO BRACKET M8
53
SCREW. UNION SCREW , Replaced By: A0009973734
53
SCREW. UNION SCREW LINE CONNECTION
56
ELBOW FITTING FROM PUMP TO CYLINDER, Replaced By: N000000006197
56
FITTING FITTING TO BRACKET
59
MUFFLER VALVE BLEEDING
59
MUFFLER BRAKE VALVE
104
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
104
SEAL RING , Replaced By: A0009940747
107
LOCK , Replaced By: A0009945448
107
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
