Поз.
Артикул
Описание
5
SUPPORT REAR AXLE
14
PLATE TOP,AIR SPRING BELLOWS
14
PLATE AIR SPRING BELLOWS TO SUBSTRUCTURE
15
17
RING AT CROSS MEMBER
18
WOODRUFF KEY BEARING BODY,6 900042
20
HEXAGON NUT. NUT STEERING WHEEL TO STEERING COLUMN
21
NUT TOP PLATE TO FRONT AXLE CROSS MEMBER
23
AIR SPRING BELLOWS FRONT AXLE
23
AIR SPRING BELLOWS REAR AXLE
23
AIR SPRING BELLOWS TRAILING AXLE LIFT
26
HELPER SPRING RUBBER BUFFER
29
SUPPORT AIR SPRING BELLOWS,BOTTOM
32
35
HEXAGON HEAD BOLT MOUNTING, TORSION BAR, ON SIDE MEMBER M18X1.5X45
35
HEXAGON HEAD BOLT. SCREW PLATE TO SIDE MEMBER M18 X 1.5 X 45
38
HEXAGON NUT BEARING BRACKET TO FRONT AXLE M18X1.5
38
NUT RUBBER MOUNTING TO BRACKET
41
41
THRUST ARM REAR AXLE,BOTTOM
73
LOCK AT CROSS MEMBER
75
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
78
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
81
SCREW. UNION SCREW LINE CONNECTION
