Поз.
Артикул
Описание
5
5
5
5
8
CABLE CONNECTOR FRAME,REAR
11
COVERING
12
12
BRACKET CABLE CONNECTOR
14
SCREW BUZZER TO WINDOW LEVEL GIRDER
14
CAPSCREW W HEXAL. DRIVEM5X20
17
LOCK WASHER T-FITTING TO BRACKET
17
LOCK WASHER BRACKET TO STEERING COLUMN END
18
LOCK WASHER CABLE TO FUSE BOX
20
NUT RELAY TO BRACKET M5
20
NUT , Replaced By: N304032005005
21
NUT SPRING-LOADED PUSH ROD
21
NUT BRACKET TO FIRE WALL
23
CLAMP LINE MOUNTING
27
SCREW , Replaced By: N304017016011
27
SCREW. HEXAGON HEAD BOLT BUZZER TO WINDOW LEVEL GIRDER M6X25
27
SCREW OVERLOAD PROTECTOR TO BRACKET
30
LOCK WASHER TRANSMISSION TO BELL HOUSING
33
WASHER6,4
36
NUT COMPRESSED AIR LINE TO LEFT SIDE MEMBER
36
NUT BRACKET TO FIRE WALL
39
39
SENDER UNIT ENGINE COMPARTMENT
40
THERMAL CONTACT. SENDER UNIT FIRE-ALARM SYSTEM
41
SHEET METAL SCREW
41
SHEET METAL SCREW BRACKET TO SUPPORT
42
WASHER BRACKET TO SUPPORT
43
BRACKET TEMPERATURE GAUGE SENDER UNIT
43
BRACKET TEMPERATURE GAUGE SENDER UNIT
44
45
GLAND , Replaced By: A0019901267
48
WASHER SPARE WHEEL CARRIER
48
WASHER
51
GROUND STRAP FROM RADIATOR TO ENGINE
57
REGULATOR ALTERNATOR 29 V
