Поз.
Артикул
Описание
5
BRAKE VALVEWABCO
5
BRAKE VALVEBOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
BRAKE VALVEKNORR
8
REPAIR KIT , Replaced By: A0004308306
8
REPAIR KIT SERVICE BRAKE VALVE BOSCH
8
REPAIR KITWABCO
8
REPAIR KIT SERVICE BRAKE VALVE BOSCH, Replaced By: A0004303506
11
NUT , Replaced By: N913004008001
11
NUT , Replaced By: N913004008004
11
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
17
SCREW. UNION SCREW LINE CONNECTION
20
SCREW. UNION SCREW , Replaced By: A0009973734
20
SCREW. UNION SCREW LINE CONNECTION
23
DISTRIBUTOR LESS CHECK VALVE
32
GUIDE BUSHING TWO-WAY VALVE TO FRAME
32
SPACER TUBE , Replaced By: A3094310249
35
SCREW DISTRIBUTOR TO FRAME SIDE MEMBER
44
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
44
NUT , Replaced By: N913004008001
47
SCREW. UNION SCREW LINE CONNECTION
53
VALVE (RELAY VALVE) BOSCH
53
VALVE (RELAY VALVE) BOSCH, REPAIR IMPOSSIBLE
53
VALVE (RELAY VALVE) KNORR
53
VALVE (RELAY VALVE) WABCO, REPAIR IMPOSSIBLE
53
VALVE (RELAY VALVE) GRAU
53
VALVE (RELAY VALVE) WABCO
59
VALVE SEATGRAU
62
GASKET34X2X6 MM,GRAU
65
SEAL RING22.3X2.4 MM,GRAU
68
SEAL RING28X2 MM,GRAU
71
SEAL RINGTO 000 429 28 95,GRAU
74
SEAL RING86X2 MM,GRAU
77
REPAIR KITKNORR
77
REPAIR KITWABCO
77
REPAIR KIT BLEEDER VALVE TO 001 431 67 05,BOSCH
77
REPAIR KIT , Replaced By: A0004301109
80
REPAIR KIT , Replaced By: A0004201071
80
VALVEBOSCH
80
VALVE GASKET KIT TO 003 429 16 44,BOSCH,UP TO 03.82
86
WASHER , Replaced By: N000125008443
86
WASHER EXHAUST MUFFLER TO STRAP
89
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
89
NUT , Replaced By: N913004008001
92
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
93
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "22"
93
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
93
SCREW PLUG , Replaced By: N000908022011
94
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
95
THRUST RING CHECK VALVE TO AIR RESERVOIR
95
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
98
O-RING CHECK VALVE TO AIR RESERVOIR
107
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
107
SEAL RING AIR RESERVOIR,CONNECTIONS: "24,34"
999
HEXALOBULAR BOLT. SCREW MANUAL PUMP BRACKET TO FENDER BRACKET
999
SCREW. HEXAGON HEAD BOLT , Replaced By: N910143008005
999
SCREW BRACKET TO SIDE MEMBER
999
SCREW , Replaced By: N304017008040
