Поз.
Артикул
Описание
22
BRACKET SPARE WHEEL HOIST
22
SPARE WHEEL HOIST ,5 365760, Replaced By: A6744000539, +001A6744000291
22
SPARE WHEEL HOIST ,5 365760, Replaced By: A6744000539, +001A6744000291
22
SPARE WHEEL HOIST
22
SPARE WHEEL HOIST
22
SPARE WHEEL HOIST
44
SPARE WHEEL HOIST
55
WORM
55
WORM
55
WORM ,5 127459, Replaced By: A6204030085, +001A6204030683
88
SHAFT
99
CLAMPING SLEEVE CRANK TO BUSHING
99
CLAMPING SLEEVE CRANK TO BUSHING
121
STOP GEAR ,5 127459, Replaced By: A6204030383, +001A6204030085
121
STOP GEAR SPARE WHEEL HOIST
121
STOP GEAR SPARE WHEEL HOIST
121
STOP GEAR
143
CABLE , Replaced By: N083331008500
143
WIRE CABLE
143
WIRE CABLE. ROPE , ORDER BY THE METER, Replaced By: N083334008000
154
WASHER WORM AND SHAFT TO BRACKET,5 127459
154
WASHER WORM AND SHAFT TO BRACKET
154
WASHER WORM AND RATCHET WHEEL TO BRACKET
154
WASHER WORM AND RATCHET WHEEL TO BRACKET
165
FITTED WASHER WORM AND SHAFT TO BRACKET
165
WASHER WORM AND SHAFT TO BRACKET
165
WASHER WORM AND SHAFT TO BRACKET
176
CLAMPING PIN BRACKET TO SUPPORT
176
CLAMPING PIN BRACKET TO SUPPORT
176
CLAMPING SLEEVE , Replaced By: N308752008000
187
DISC SPRING WORM AND SHAFT TO BRACKET
198
COVERING PROTECTION PLATE TO BRACKET
220
SCREW , Replaced By: N304017006020
220
SCREW LICENSE PLATE TO BRACKET
220
SCREW COVER PLATE TO BRACKET
231
WASHER , Replaced By: N009021006208
231
WASHER COMPRESSED AIR LINE TO BRACKET
242
NUT , Replaced By: N913004006001
242
NUT PUMP TO BRACKET
250
BRACKET SPARE WHEEL HOIST, ONLY 6-MM-THICK PART MAY BE USED
260
BRACKET SPARE WHEEL HOIST
330
SCREW REAR EXHAUST PIPE TO MUFFLER
330
SCREW REAR EXHAUST PIPE TO MUFFLER
330
SCREW LEFT AND RIGHT BEARING BRACKETS TO CAB
330
SCREW , Replaced By: N308676012011
330
SCREW CONSOLE TO SIDE MEMBER
330
SCREW CONSOLE TO SIDE MEMBER
330
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X40
330
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X40
330
SCREW EXHAUST PIPE TO BRACKET
330
SCREW , Replaced By: N308676012015
330
SCREW , Replaced By: N308676012026
330
SCREW LEFT AND RIGHT CONSOLES TO CAB
352
WASHER RADIATOR TO RUBBER MOUNTING
352
WASHER RADIATOR TO RUBBER MOUNTING
352
WASHER , Replaced By: N000125010532
363
WASHER
370
WASHER SPARE WHEEL TO BRACKET
374
NUT , Replaced By: N910113010000
374
NUT STRAP TO BRACKET
374
NUT STRAP TO BRACKET
385
NUT SPARE WHEEL HOIST TO FRAME
385
NUT SUPPORT TO SIDE MEMBER
385
NUT SUPPORT TO SIDE MEMBER
396
REINFORCEMENT REAR CONSOLE
396
REINFORCEMENT REAR CONSOLE
396
REINFORCEMENT , Replaced By: A6754030808
399
ADJUSTING WASHER SPARE WHEEL HOIST TO FRAME
404
WASHER , Replaced By: N006902011100
404
WASHER BRACKET TO FRAME
404
WASHER UNDERRUN PROTECTION AND BRACKET TO FRAME
404
WASHER , Replaced By: N006902011102
407
REINFORCEMENT SPARE WHEEL HOIST TO FRAME
517
SHAFT
528
CLAMPING SLEEVE TUBE AND SHAFT TO JOINT SLEEVE 6X22
748
STAY
752
STAY ,5 365760
759
WASHER , Replaced By: N000125017016
759
WASHER BRACKET TO FRAME
759
WASHER BRACKET TO FRAME
770
NUT SPARE WHEEL CARRIER TO SIDE MEMBER
770
NUT , Replaced By: N308673016001
999
PLATE SPARE WHEEL HOIST TO CROSS MEMBER
999
PIPE
999
BRACKET
999
CRANK SPARE WHEEL HOIST
