Поз.
Артикул
Описание
8
HEATER UNIT24 V,5 385341
8
HEATER UNIT24 V,5 385342
16
CONTROL UNIT ,5 385341
16
CONTROL UNIT ,5 385342
24
BRACKET ,5 385341
32
PULSE SENDER UNIT (IGNITION ELEMENT SPINDLE),5 385341
32
PULSE SENDER UNIT (IGNITION ELEMENT SPINDLE),5 385342
35
PLUG SPARK PLUG CONNECTOR,5 385342
40
ELECTRIC MOTOR
48
SWITCH SOLENOID SWITCH
56
REPAIR KIT
64
SEAL
72
IGNITION ELECTRODE
80
FLAME CONTROLLER ,5 385341
80
FLAME CONTROLLER ,5 385342
88
NOZZLE
96
PUMP FUEL-OIL PUMP,5 385341
96
PUMP FUEL-OIL PUMP,5 385342
96
PUMP , Replaced By: A0008356664, +001A0008350311
98
VALVE ,5 385342
100
FILTER ,5 385342
104
PLATE ,5 385342
104
PLATE , Replaced By: A0008350311
104
PLATE , Replaced By: A0008350311
112
SWITCH ,5 385342
114
TEMPERATURE SENSOR ,5 385342
114
TEMPERATURE SENSOR , Replaced By: A0008308672
116
SEAL RING , Replaced By: N007603010110
116
SEAL RING PNEUMATIC VALVE
120
SWITCH GREEN,5 385341
128
SWITCH GREEN/RED,5 385341
132
FUSE AMBER,5 385342
132
FUSE AMBER,5 385341
136
SEAL RING ,5 385342
144
TELL-TALE LAMP HEATER UNIT
152
SWITCH
152
SWITCH , Replaced By: A0018207110
160
TUBE (EXHAUST LINE)
168
FILTER FUEL
999
BRACKET HEATER UNIT
999
PIPE FROM ENGINE TO HEATER, NOT USED
999
HOSE FROM SCREW FITTING TO RECIRCULATING PUMP
999
HOSE FROM HEATING WATER PIPE TO HEATER
999
GROMMET LINE PASSAGE AT SIDE MEMBER
999
GROMMET , Replaced By: A4069975081
999
SEAL RINGTO 942 500 15 98
999
SEAL RING
999
SWITCH
999
BLOWER
999
SCREW BRACKET TO BATTERY/APPARATUS SUPPORT
999
SCREW BATTERY MOUNTING
999
RUBBER BUFFER SUPPORT TO BRACKET
999
PUMP
999
SWITCH
999
SWITCH , Replaced By: A0018354506
999
NUT BRACKET TO BRACKET
999
CONTROL UNITGGVS
999
CONTROL UNITSTANDARD
999
HEATER PLUG
999
TEMPERATURE SENSOR
999
BURNER
999
LAMP , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0005430142
999
CLOCK60 MIN
999
AUXILIARY PUMP (METERING PUMP)
