Поз.
Артикул
Описание
5
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
5
HOSE , Replaced By: A0009872827
8
FITTING (PARTS KIT),LINE RUPTURE
11
UNION NUT LINE CONNECTION
11
UNION NUT LINE CONNECTION, Replaced By: N000000006239
14
SEAL CONE LINE CONNECTION
14
GLAND , Replaced By: A0019901967
17
SLEEVE LINE CONNECTION
23
CONNECTOR RELEASE BEARING LUBRICATION
23
CONNECTOR , Replaced By: A0019904078
26
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
29
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
81
RESERVOIR COMPRESSED AIR 20 L, TO VOSS 232, FOR VEHICLES WITH VOSS 230 CONNECTOR: ADD. MOUNT FITTING "A 004 997 82 72" WITH O-RING "A 000 987 04 46" AND THRUST RING "A 000 997 02 03" TO AIR RESERVOIR
81
RESERVOIR COMPRESSED AIR 20 L
87
CONSOLE AIR RESERVOIR
93
BRACKET AT CONSOLE, SIMPLE PART-PLEASE HAVE SHOP MADE
108
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
108
SCREW , Replaced By: N308676012012
111
WASHER BRACKET TO FRAME
111
WASHER UNDERRUN PROTECTION AND BRACKET TO FRAME
111
WASHER , Replaced By: N006902011102
111
WASHER , Replaced By: N006902011100
111
WASHER RADIATOR TO RUBBER MOUNTING
111
WASHER , Replaced By: N000125010532
114
NUT STRAP TO BRACKET
114
NUT , Replaced By: N910113010000
117
STRAP AIR RESERVOIR TO CONSOLE
135
NUT STRAP TO BRACKET
135
NUT , Replaced By: N910113010000
144
THRUST RING CHECK VALVE TO AIR RESERVOIR
144
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
147
O-RING CHECK VALVE TO AIR RESERVOIR
162
VALVE DRAIN, Replaced By: A0004322107
162
VALVE. DRAIN VALVE DRAIN
162
VALVE. DRAIN VALVE DRAIN
162
VALVE DRAIN, Replaced By: A0004322107
162
VALVE DRAIN, Replaced By: A0004322407
165
THRUST RING CHECK VALVE TO AIR RESERVOIR
165
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
168
O-RING CHECK VALVE TO AIR RESERVOIR
171
VALVE (OVERFLOW VALVE) GRAU
171
VALVE (OVERFLOW VALVE) WABCO
174
DIAPHRAGM
174
DIAPHRAGM
177
SCREWWABCO
183
FITTING SHUTTLE VALVE,CONNECTION: "20"
186
NUT CHECK VALVE TO AIR RESERVOIR
189
FITTING OVERFLOW VALVE,CONNECTION: "10"
192
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
195
THRUST RING CHECK VALVE TO AIR RESERVOIR
195
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
198
O-RING CHECK VALVE TO AIR RESERVOIR
201
NUT CHECK VALVE TO AIR RESERVOIR
