Поз.
Артикул
Описание
34
PLASTIC PIPE RISING PIPE 4X6 MM
34
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
44
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
47
LOCK LINE CONNECTION
47
LOCK , Replaced By: A0009945448
50
REPAIR KIT , Replaced By: A0309971748
50
REPAIR KIT COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
54
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
64
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
74
DISTRIBUTOR HOSE WIDTH, 6 MM
84
CONNECTOR LINE MOUNTING
114
SCREW. UNION SCREW LINE CONNECTION
114
SCREW. UNION SCREW , Replaced By: A0009973734
124
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
134
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION
134
CONNECTOR , Replaced By: A0029905378
164
VALVE , Replaced By: A0044293144
174
VALVE , Replaced By: A0044293244
174
VALVE (OVERFLOW VALVE) GRAU
184
VALVE (OVERFLOW VALVE) WABCO
184
VALVE , Replaced By: A0044293144
194
DIAPHRAGM
204
VALVE
214
REPAIR KITTO 001 429 52 44
224
REPAIR KITBOSCH
244
BRACKET OVERFLOW VALVE,CONNECTION: "20"
244
BRACKET OVERFLOW VALVE,CONNECTION: "10"
254
SCREW COVER PLATE TO COVER PLATE M 6 X 12
254
SCREW , Replaced By: N304017006018
264
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
274
FITTING AIR RESERVOIR,CONNECTIONS: "10,20"
284
THRUST RING CHECK VALVE TO AIR RESERVOIR
284
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
294
O-RING CHECK VALVE TO AIR RESERVOIR
304
HOLLOW SCREW HEATING CONNECTION
314
SEAL RING LINE CONNECTION
324
LOOM TIE LINE MOUNTING 280 MM
999
DIAPHRAGM , Replaced By: A0004290745
999
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION
999
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION
999
SEAL RING , Replaced By: A0009940747
999
LOCK RING LINE CONNECTION
999
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
999
T-FITTING EXHAUST BRAKE LINE CONNECTION
999
COUPLING COMPRESSED-AIR-LINE PLUG-CONNECTION
999
PLUG COMPRESSED-AIR-LINE PLUG-CONNECTION
999
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
999
CONNECTOR DISTRIBUTOR TO CAB
999
PLUG BLEEDING,D 013038
999
SCREW , Replaced By: N304017006034
999
SCREW COVER PLATE TO COVER PLATE M 6 X 10
