Поз.
Артикул
Описание
8
CROSS MEMBER TRANSMISSION,5 519079
8
CROSS MEMBER ,5 519078, Replaced By: A6753120011, +001A6753112260, +001A6753112360, +001A6753112383, +001A6733121152, +001A6733121252, +008N000961012052, +006N000961012151, +014N913004012008
16
REINFORCEMENT RIGHT
16
REINFORCEMENT LEFT
16
REINFORCEMENT LEFT
16
REINFORCEMENT RIGHT
20
REINFORCEMENT LEFT
20
REINFORCEMENT RIGHT
24
ANGLE , Replaced By: A6733121152
24
ANGLE , Replaced By: A6733121252
24
ANGLE LEFT,5 519078
24
ANGLE LEFT
28
SCREW , Replaced By: N304017010047
28
SCREW , Replaced By: N304017010040
28
SCREW CONNECTOR TO REAR SHIFTING ROD
28
SCREW STRUT TO CROSS MEMBER M 10X25
32
NUT GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
33
SCREWM 12X13X18X35
34
NUT , Replaced By: N910113012003
34
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
36
RIVET12X58 MM, TO BE ADAPTED DURING ASSEMBLY
40
SCREW BRACKET TO FRAME M 12X35
44
WASHER BRACKET TO FRAME
48
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
48
NUT , Replaced By: N910113012003
999
ANGLE LEFT
999
CROSS MEMBER TRANSMISSION NO.2, NOT INCLUDED IN RANGE OF DELIVERY OF FRAME
999
CROSS MEMBER
