Поз.
Артикул
Описание
5
BRACKET OIL TANK,5 553319
9
HOSE ,K 055044
18
LINE (SUCTION LINE),FROM OIL TANK TO PUMP,5 163366
18
LINE (SUCTION LINE),FROM OIL TANK TO PUMP,5 529814K 055043
18
LINE (SUCTION LINE),FROM OIL TANK TO PUMP,5 138294
18
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP
27
CLAMP HOSE TO FITTING AND TO OIL TANK
36
HOSE (SUCTION LINE),FROM OIL TANK TO PUMP,5 138294
45
LINE (SUCTION LINE),FROM OIL TANK TO PUMP,5 3341845 955600 SA 083.128/24/25: 5 903781-5 955600
45
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
45
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
45
LINE ,K 055043K 126843
54
UNION NUT LINE CONNECTION, Replaced By: N000000006243
54
NUT LINE CONNECTION
63
GLAND , Replaced By: A0019901267
63
SEAL CONE LINE CONNECTION
72
ELBOW FITTING SUCTION LINE TO OIL PUMP
81
THRUST RING SUCTION LINE TO OIL PUMP
90
SEALING CORD SUCTION LINE TO OIL PUMP
99
NUT SUCTION LINE TO OIL PUMP
108
SCREW CONNECTION DELIVERY LINE TO PUMP
117
LINE (SUCTION LINE),FROM OIL TANK TO PUMP,K 244309
117
LINE FROM PUMP TO HIGH PRESSURE HOSE
117
LINE FROM PUMP TO HIGH PRESSURE HOSE
117
LINE FROM PUMP TO HIGH PRESSURE HOSE,K 126843
126
UNION NUT LINE CONNECTION
126
UNION NUT LINE CONNECTION, Replaced By: N000000006239
135
GLAND , Replaced By: A0019901967
135
SEAL CONE LINE CONNECTION
144
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
144
HOSE POWER-STEERING-PUMP-TO-STEERING-BOX DELIVERY LINE
144
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
144
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
144
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
144
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
144
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
144
HOSE (DELIVERY LINE),FROM PUMP TO STEERING,K 126844
153
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO STEERING BOX,5 163366
153
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO FITTING,5 955601
153
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO STEERING BOX,5 529814K 055043
153
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO STEERING BOX
153
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO FITTING
153
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO STEERING BOX
162
UNION NUT LINE CONNECTION, Replaced By: N000000006239
162
UNION NUT LINE CONNECTION
162
NUT. UNION NUT LINE CONNECTION
171
GLAND , Replaced By: A0019901967
171
CUTTING RING. GLAND LINE CONNECTION
171
SEAL CONE LINE CONNECTION
180
SCREW-IN FITTING FUEL FEED,AT WATER SEPARATOR
180
SCREW-IN FITTING LINE CONNECTION TO TRANSMISSION
189
SCREW-IN FITTING DELIVERY LINE TO PUMP
189
FITTING RETURN LINE TO STEERING
198
LINE (RETURN LINE),FROM STEERING TO OIL TANK,5 163366
198
LINE (RETURN LINE),FROM STEERING TO OIL TANK
198
LINE FROM STEERING GEAR TO OIL TANK,5 477370K 112897
198
LINE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6744661865
198
LINE12 MM, ORDER BY THE METER4 691315
198
LINE , Replaced By: A0004291001
207
HOSE ,K 055044
207
HOSE (RETURN LINE),FROM STEERING TO OIL TANK
999
ANGLE LINE MOUNTING
999
LINE , Replaced By: A0004292301
999
LINE (DELIVERY LINE) FROM FITTING TO STEERING,K 126843
999
LINE FITTING TO STEERING BOX,5 477370K 112897
999
HOSE (RETURN LINE),FROM STEERING TO OIL TANK,K 055043
999
SCREW CONNECTION DELIVERY LINE TO STEERING
999
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
