Поз.
Артикул
Описание
5
PLASTIC PIPE RISING PIPE 4X6 MM
5
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
8
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
11
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
14
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
17
HOLLOW SCREW HEATING CONNECTION
20
SEAL RING LINE CONNECTION
23
SCREW. UNION SCREW LINE CONNECTION
23
SCREW. UNION SCREW , Replaced By: A0009973734
26
SEAL RING , Replaced By: A0009940747
26
LOCK RING LINE CONNECTION
29
LOCK , Replaced By: A0009945448
29
LOCK LINE CONNECTION
32
REPAIR KIT , Replaced By: A0309971748
32
REPAIR KIT COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
35
LOOM TIE LINE MOUNTING 280 MM
35
LOOM TIE LINE MOUNTING
38
VALVE DIFFERENTIAL LOCK CONTROL WABCO
38
VALVE DIFFERENTIAL LOCK CONTROL BOSCH
41
PROTECTIVE CAPBOSCH
44
ACTUATING PARTWABCO
47
SPRING INSIDE WABCO
50
SEAL RING INSIDE WABCO
53
SEAL RING
56
SEAL RING TOP WABCO
59
SEAL RING
62
WASHER AT TWO-WAY VALVE
65
UNIT IDENTIFICATION PLATE 2/3-WAY VALVE TO ENGINE TUNNEL
68
NUT 4/3-WAY VALVE TO SUBSTRUCTURE
