Поз.
Артикул
Описание
5
STEERING BRACKET ,D 007756
5
STEERING BRACKET
5
STEERING BRACKET
8
SCREW BRACKET MOUNTING
11
SCREW ENGINE SUPPORT TO SIDE MEMBERS M 12X40
14
NUT BRACKET TO SIDE MEMBER M12X1.5
17
SCREW STEERING TO STEERING BRACKET
20
PITMAN ARM
23
DRAG LINK
23
DRAG LINKLEMFOERDER
23
DRAG LINKGEMMER THOMPSON
26
BOOT FIXED PART OF JOINT TO 345 460 88 05
29
NUT BALL PIVOT TO STEERING ARM
32
COTTER PINROCKINGER TYP 260 G140
35
STEERING INTERMEDIATE ARM , USED WITH AIR BRAKE
38
GREASE NIPPLE
41
TRUNNION BEARING STEERING INTERMEDIATE ARM
44
HEXAGON HEAD BOLT BEARING BRACKET TO SIDE MEMBER M 12X50
47
SCREW BRACKET MOUNTING
50
NUT BRACKET TO SIDE MEMBER M12X1.5
53
SEAL RING
56
TAPERED ROLLER BEARING
56
TAPERED ROLLER BEARING
56
TAPERED ROLLER BEARING FRONT
59
TAPERED ROLLER BEARING INTERMEDIATE LEVER TO BEARING BRACKET
59
TAPERED ROLLER BEARING
59
TAPERED ROLLER BEARING
62
THRUST WASHER STEERING INTERMEDIATE ARM BEARING
65
NUT BALL PIVOT TO STEERING ARM
68
COTTER PINROCKINGER TYP 260 G140
71
CAP AT STEERING INTERMEDIATE ARM
74
DRAG LINKNAKATA, USED WITH AIR BRAKE607675
74
DRAG LINK REAR, USED WITH AIR BRAKE607675
77
DUST CAPTO 345 460 81 05,376 460 01 05
80
CLAMPING RING FIXED PART OF JOINT TO 345 460 86 05, USED WITH AIR BRAKE, 341.041,042,044 FROM CHASSIS A 059729 ALSO INSTALLED ON A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059425,A 059426,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
86
DUST CAPTO 345 460 81 05,376 460 01 05
89
CLAMPING RING FIXED PART OF JOINT TO 345 460 86 05, USED WITH AIR BRAKE, 341.041,042,044 FROM CHASSIS A 059729 ALSO INSTALLED ON A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059425,A 059426,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
92
CLAMP JOINT TO TIE ROD,1 2165311 248012
92
CLAMPTO 345 460 80 05, 345 460 79 05
95
SCREW SHACKLE TO TORSION BAR
98
NUT , Replaced By: N910113012003
101
NUT BALL PIVOT TO STEERING ARM
104
COTTER PINROCKINGER TYP 260 G140
