Поз.
Артикул
Описание
6
RESERVOIR AIR RESERVOIR
13
VALVE AUTOMATIC DRAIN VALVE CONNECTION BW 101321
14
VALVE DRAIN VALVE
14
VALVE DRAIN VALVE
20
VALVE AT AIR RESERVOIR
27
ELBOW FITTING
28
FITTING45° 3/8
32
FITTING AT AIR RESERVOIR
32
FITTING AT AIR RESERVOIR
32
FITTING AT AIR RESERVOIR
35
T-FITTING
35
T-FITTING AT AIR RESERVOIR
35
T-FITTING , Replaced By: N210503000020
41
PLUG AT AIR RESERVOIR
42
FASTENER3/8-18 NPTF
44
BRACKET AIR RESERVOIR
53
BRACKET AIR RESERVOIR
53
BRACKET , Replaced By: A6854320540
70
ELBOW FITTING90GR. 1/2NPTFX5/8T
70
ELBOW FITTING45 - 3/8 NPT
71
SCREW AIR RESERVOIR BRACKET TO FRAME 3/8-16X1/4 FG 8
80
WASHER SHIFTING ROD 3/8
85
NUT. PART NAME MISSING NUT
98
ELBOW FITTING BRAKE VALVE 3/8 NPTFM X 1/4 NPTFH
999
VALVE PRESSURE RELIEF VALVE
999
VALVE PRESSURE CONTROL VALVE
999
PART NAME MISSING SCREW
999
PLUG AT AIR RESERVOIR
999
PLUG REGENERATION TANK BR 0,6MPT
999
PLUG OIL PRESSURE GAUGE
999
T-FITTING AT AIR RESERVOIR
999
T-FITTING AT AIR RESERVOIR
999
FITTING AT AIR RESERVOIR, Replaced By: N210500000011
999
FITTING AT AIR RESERVOIR
999
FITTING
999
METAL SECTION , ORDER BY THE METER
999
CLIP
