Поз.
Артикул
Описание
10
PLASTIC PIPE BLUE 3/8, ORDER BY THE METER
15
FITTING
20
ELBOW FITTING
25
ELBOW FITTING BRAKE VALVE 3/8 NPTFM X 1/4 NPTFH
29
ELBOW FITTING45 GR. 1/4 NPTFM X 3/8 T
30
ELBOW FITTING90 GR. 1/4 NPTFM X 3/8T
71
T-FITTING ,M 009558
72
STRAP TO HOSE
80
VALVEWABCO
82
BRACKET VALVE
84
BRACKET
90
PLUG OIL PRESSURE GAUGE
95
INSULATING HOSE
100
CONNECTOR
110
SCREW5/16-18
110
PART NAME MISSING SCREW
130
PART NAME MISSING NUT
140
PART NAME MISSING NUT3/8" - 16
999
PART NAME MISSING , Replaced By: A6889900040
999
NUT. PART NAME MISSING NUT
999
PART NAME MISSING CONSOLE TO FRAME 1/2 -13
999
SLEEVEL00 SL13R
999
REPAIR KIT LINKAGE NEW 90554687
999
VALVE
999
ELBOW FITTING
999
NUT LEVER TO SHIFTING SHAFT
999
FITTING1/8" NPT X 1/4" T
999
ELBOW FITTING ,M 027041
999
ELBOW FITTING AT AIR RESERVOIR
999
FITTING90 GR. 1/4 NPTFM X 1/4 NPTH
999
PLUG
999
BRACKET
999
LOOM TIE
999
VALVE
999
VALVE
999
VALVE
999
LINK
999
BRACKET VALVE
999
BRACKET
999
BRACKET
999
WASHER SHIFTING ROD 3/8
999
WASHER VALVE TO BRACKET 5/16-.640
999
SCREW BRACKET MOUNTING 1/4-20
999
SCREW LINE MOUNTING 5/16-18
999
SCREW 5/16 -1
999
LOOM TIE
999
NUT COMPRESSED AIR LINE TO CROSS MEMBER1/4,M 033721
999
NUT5/8-11,M 026123
999
NUT3/4
999
WASHER1/4
999
LOOM TIE
999
COTTER PIN3/32X1-1/4
