Поз.
Артикул
Описание
5
BEARING BRACKET BRAKE PEDAL
5
BEARING BRACKET , Replaced By: A6882947001
8
BEARING BRACKET , Replaced By: A3842947201
8
BEARING BRACKET BRAKE PEDAL
20
GASKET BEARING BRACKET TO CAB
20
GASKET , Replaced By: A6452940280
23
GASKET BEARING BRACKET TO CAB
32
SCREW AIR DUCT TO CAB
38
WASHER BRACKET TO FENDER BRACKET
44
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
47
SPRING WASHER CABLE TO ALTERNATOR
50
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
53
STOP CLUTCH PEDAL
53
STOP STOP TO BEARING BRACKET
56
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
59
NUT BRACKET TO FIRE WALL
62
STOP CLUTCH PEDAL AND BRAKE PEDAL
62
STOP CLUTCH PEDAL STOP
63
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
65
STOP CLUTCH PEDAL
65
STOP , Replaced By: A6882917286
65
STOP
68
STOP , Replaced By: A6882917186
68
STOP BRAKE PEDAL
68
STOP
68
STOP , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A6732910286
71
PEDAL CLUTCH
74
PAD , Replaced By: A1072910182
77
NEEDLE BEARING CLUTCH PEDAL
77
NEEDLE BEARING
80
PIN CLUTCH PEDAL39 MM(M10) TO A6952907216
83
NUT AIR CLEANER ELEMENT
89
PEDAL BRAKE, NO.8650I.......I I I II .......INO.9985I I I II I
95
BUSHING , Replaced By: A1242920050
98
PAD , Replaced By: A1072910182
101
ROD , Replaced By: A3822908419
101
BEARING BRACKET
103
NEEDLE BEARING JOINT TO PIN
103
NEEDLE BEARING JOINT TO PIN
103
NEEDLE BEARING JOINT TO PIN
103
NEEDLE BEARING JOINT TO PIN
105
NUT GEARSHIFT LEVER KNOB TO GEARSHIFT LEVER
110
SPRING RETAINER SPRING TO PUSH ROD
116
SPRING (DEAD CENTER SPRING) 35 MM
116
SPRING CLUTCH PEDAL RESET,B 974884
116
SPRING CLUTCH PEDAL RESET,B 974885
122
SPRING RETAINER SPRING TO PUSH ROD
128
CLIP SPRING TO PUSH ROD
132
ROD , Replaced By: A3822900093
132
REPAIR KIT , Replaced By: A3862900039
132
SPRING PARTS KIT
134
PIN , Replaced By: A3842917074
134
PIN PUSH ROD TO CLUTCH PEDAL52 MM,B 910380
137
WASHER BRACKET TO FENDER BRACKET
140
LOCK PLATE
141
LOCK RING PUSH ROD TO PEDAL
143
WASHER CLUTCH PEDAL TO BEARING BRACKET
146
PIN CLUTCH PEDAL TO BEARING BRACKET
149
LOCK CLUTCH AND BRAKE PEDAL PINS TO BEARING BRACKETS
149
LOCK , Replaced By: A6732920073
152
WASHER PLUG SOCKET TO BRACKET
155
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
158
SPACER WASHER BRAKE PEDAL TO BEARING BRACKET
164
SPRING BRAKE PEDAL TO BEARING BRACKET
170
PIN CLUTCH PEDAL TO BEARING BRACKET
170
PIN , Replaced By: A6452940074
173
LOCK , Replaced By: A6732920073
173
LOCK CLUTCH AND BRAKE PEDAL PINS TO BEARING BRACKETS
176
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
179
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
188
PIN BRAKE PEDAL TO BRAKE VALVE
188
PIN PISTON ROD TO LEVER, 415 5 014668 416 5 000515 417 4 972023
194
WASHER PULL ROD TO SHIFT LEVER
194
WASHER , Replaced By: N000433010510
197
COTTER PIN PISTON ROD TO BRAKE PEDAL 3,2X20
197
COTTER PIN CONNECTOR TO BRAKE PRESSURE REGULATOR LEVER
999
STUD
