Поз.
Артикул
Описание
5
REAR SPRING 8-LEAF
5
REAR SPRING 10-LEAF,D 144514
8
SPRING LEAFNO.1, TO 688 320 03 06,D 144514
11
SPRING LEAFN0.2
11
SPRING LEAFNO.2, TO 688 320 03 06,D 144514
14
SPRING LEAFN0.3
14
SPRING LEAFNO.3, TO 688 320 03 06,D 144514
15
SPRING LEAFN0.4
15
SPRING LEAFNO.4,TO 688 320 03 06,D 144514
17
SPRING LEAFNO.5, TO 688 320 03 06,D 144514
20
SPRING LEAFN0.6
22
SPACER
23
SPRING BOLT REAR SPRING M10X150
26
NUT SPRING BOLT
29
SPACER TUBE , Replaced By: A0003213253
32
SCREWM 8X90
35
NUT HORN TO BRACKET M8
38
RUBBER BUFFER SPRING EYE,FRONT
41
RUBBER MOUNTING REAR SPRING TO SPRING SHACKLE AND TO SPRING REAR BRACKET
44
SPACER TUBE REAR SPRING TO SPRING SHACKLE
47
WASHER REAR SPRING & SPRING SHACKLE TO REAR SPRING BRACKET
50
NUT , Replaced By: N910113018004
53
SCREW REAR SPRING TO SPRING SHACKLE
56
SHACKLE REAR SPRING TO REAR SPRING REAR BRACKET
56
SHACKLE REAR SPRING TO REAR SPRING REAR BRACKET
57
RUBBER MOUNTING REAR SPRING TO SPRING SHACKLE AND TO SPRING REAR BRACKET
59
PLATE FRONT SPRINGS TO FRONT AXLE
68
U-BOLT REAR SPRING TO REAR AXLE M 16X1,5X210MM
71
SPHERICAL WASHER FRONT SPRINGS TO FRONT AXLE,5 468450
74
NUT REAR AXLE TO TO REAR SPRINGS,B 825283
999
SPRING LEAF PARTS KIT N0.1
999
SPRING LEAF PARTS KIT N0.5
999
SPRING LEAF PARTS KIT N0.8
999
SPRING LEAFN0.7
