Поз.
Артикул
Описание
5
TORSION BAR FRONT STABILIZER
5
TORSION BAR , Replaced By: A6883200611
8
BEARING SHACKLE TO STABILIZER, Replaced By: A9793200173
8
BEARING
8
BEARING BRACKET TO SHACKLE
8
BEARING BRACKET TO SHACKLE
11
RUBBER MOUNTING TORSION BAR TO FRONT AXLE
14
BRACKET TORSION BAR TO FRONT AXLE
17
BRACKET TORSION BAR TO FRONT AXLE
20
CLAMP TORSION BAR TO FRONT AXLE
23
NUT BRACKET TO SIDE MEMBER M12X1.5
26
BRACKET LEFT
26
BRACKET , Replaced By: A6883200343
26
BRACKET , Replaced By: A6883200443
26
BRACKET RIGHT
29
BEARING SHACKLE TO STABILIZER, Replaced By: A9793200173
29
BEARING BRACKET TO SHACKLE
29
BEARING BRACKET TO SHACKLE
32
32
35
SCREW SUPPORT TO SIDE MEMBER M 12X1.5X30
35
SCREW SUPPORT TO SIDE MEMBER M 12X1.5X35
38
WASHER SUPPORT TO FRAME,D 127794
41
NUT ALTERNATOR TO SUPPORT
44
SCREW CROSS MEMBER TO SIDE MEMBERS
47
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
50
SHACKLE
54
SCREW VIBRATION ABSORBER TO FRAME M 12X1.5X55
57
NUT ALTERNATOR TO SUPPORT
60
62
RUBBER MOUNTING TOP AND BOTTOM
62
GUMMIHULSE. RUBBER MOUNTING TOP AND BOTTOM, Replaced By: A0003238685
65
68
71
BUSHING BOTTOM
74
74
77
HEXAGON HEAD BOLT BRACKET TO SIDE MEMBER M12X1.5X35
80
NUT BRACKET TO SIDE MEMBER M12X1.5
86
89
92
SCREW BRACKET TO SIDE MEMBER
95
SCREW APPARATUS SUPPORT TO FRAME M 14X1.5X85
98
NUT BRACKET TO BATTERY CASE
101
SPACER TUBE SHOCK ABSORBER TO FRONT AXLE
104
HEXAGON HEAD BOLT AT FRAME, REAR M14X1.5X150
107
WASHER SHOCK ABSORBER TO FRONT AXLE
110
NUT SUPPORT TO FRAME
113
RUBBER SPRING FRONT SPRING STOP
116
BRACKET RUBBER SPRING TO BRACKET
