Поз.
Артикул
Описание
5
BEARING BRACKET (PEDAL BEARING BRACKET)
5
BEARING BRACKET (PEDAL BEARING BRACKET)
8
THREADED INSERT
17
GASKET BEARING BRACKET TO CAB
26
STUD
38
WASHER REAR FOGLAMP TO BRACKET
46
NUT HORN TO BRACKET M8
52
STOP CLUTCH PEDAL
52
STOP CLUTCH PEDAL,5 219889
62
SCREW BATTERY POS. CABLE TO BRACKET,PB004444
65
STOP
68
PEDAL CLUTCH,5 219889
68
86
PAD , Replaced By: A1072910182
89
NEEDLE BEARING CLUTCH PEDAL
89
NEEDLE BEARING
89
NEEDLE BEARING CLUTCH PEDAL
92
SPACER TUBE CLUTCH PEDAL
95
WASHER CLUTCH PEDAL TO BEARING BRACKET
98
PIN CLUTCH PEDAL TO BEARING BRACKET
104
LOCK CLUTCH AND BRAKE PEDAL PINS TO BEARING BRACKETS
107
SCREW CLAMP MOUNTING M 6X16
110
LOCK WASHER CABLE TO FUSE BOX
113
PIN CLUTCH PEDAL RESET
116
SPRING RETAINER CLUTCH PEDAL RESET
119
119
SPRING CLUTCH PEDAL RESET
122
SPRING RETAINER CLUTCH PEDAL RESET
125
ROD CLUTCH PEDAL RESET
128
NUT CLUTCH PEDAL RESET
131
BRACKET LEFT SUPPORTING ARM
134
STOP CLUTCH PEDAL RESET,5 219889
137
LOCKING WASHER. LOCK PLATE CLUTCH PEDAL RESET
140
WASHER GROUND CABLE
143
STOP BRAKE PEDAL
143
BRACKET BRAKE PEDAL,D 383712
149
STOP BRAKE PEDAL
152
HEXAGON HEAD BOLT
155
PEDAL BRAKE
161
PAD , Replaced By: A1072910182
164
BUSHING ROD TO CLUTCH PEDAL
164
BUSHING , Replaced By: A1242920050
167
PIN BRAKE PEDAL TO BEARING BRACKET
179
LOCK CLUTCH AND BRAKE PEDAL PINS TO BEARING BRACKETS
182
SCREW BATTERY POS. CABLE TO BRACKET,PB004444
188
LOCK WASHER CABLE TO FUSE BOX
194
PIN ROD TO BRAKE PEDAL
200
WASHER CLUTCH LINING WEAR INDICATOR
206
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
212
SPRING BRAKE PEDAL RELEASE SPRING
215
PIN ROD TO CLUTCH PEDAL
218
SPACER RING ROD TO CLUTCH PEDAL
221
ROD TWO-CIRCUIT-BRAKE-VALVE CONTROL
227
YOKE OPERATING ROD
233
NUT CLUTCH PEDAL PISTON ROD
239
BRACKET CLUTCH PEDAL
242
SPRING PEDAL RETURN SPRING
242
SPRING , Replaced By: A3829937110
