Поз.
Артикул
Описание
5
BRAKE VALVE SERVICE BRAKE WABCO
5
BRAKE VALVE SERVICE BRAKE KNORR
8
BRAKE VALVE (SERVICE BRAKE VALVE) KNORR
8
BRAKE VALVE (SERVICE BRAKE VALVE) WABCO
9
MUFFLER VALVE BLEEDING
10
REPAIR KIT SMALL SCOPE TO 345 431 70 05
10
REPAIR KIT SMALL SCOPE TO 345 431 71 05
10
REPAIR KIT LARGE SCOPE TO 695 431 71 04
10
REPAIR KIT SMALL SCOPE TO 695 431 74 04
12
SEALING CORD SUCTION LINE TO OIL PUMP
13
REPAIR KIT , Replaced By: A0014300460
14
T-FITTING BETWEEN THE LINES
15
GASKET KIT TWO-CIRCUIT BRAKE VALVE TO 002 431 87 05
18
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
20
VALVE QUICK-RELEASE VALVE KNORR
22
HOSE PRESSURE REGULATOR,CONNECTION: "3"
23
REPAIR KITTOA 382 429 70 44, A 693 429 71 44
24
HOSE HAND BRAKE VALVE
25
26
HOSE HAND BRAKE VALVE
27
BRACKET QUICK-RELEASE VALVE
30
VALVE (RELAY VALVE) KNORR
33
REPAIR KIT. VALVE REPAIR KIT TO 695 429 71 44
37
BRACKET (RELAY VALVE)
40
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
43
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
46
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
49
THRUST RING CHECK VALVE TO AIR RESERVOIR
52
O-RING CHECK VALVE TO AIR RESERVOIR
55
FITTING , Replaced By: A0029971172
55
55
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20", Replaced By: N000000006191
58
ADAPTER FITTING RELAY VALVE
61
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
61
SCREW PLUG SECONDARY CONSUMING UNIT AIR RESERVOIR
64
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
67
THRUST RING LOCKING VALVE
70
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
73
FITTING , Replaced By: A0019909871
73
ELBOW FITTING DIAPHRAGM CYLINDER,CONNECTION: "1,11"
73
ELBOW FITTING RELAY VALVE,CONNECTION: "20"
79
GASKET BRAKE BOOSTER ASSEMBLY TO FIRE WALL
79
GASKET BRAKE SHOE WITH LINING
85
SCREW LINES TO BRACKET
85
SCREW , Replaced By: N910143008002
88
SCREW SHIFT LEVER TO BRACKET M8X30
91
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
94
WASHER TRAILER PLUG SOCKET TO BRACKET
97
NUT HORN TO BRACKET M8
97
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
100
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
108
SCREW. UNION SCREW LINE CONNECTION
111
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
111
113
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
