Поз.
Артикул
Описание
5
11
SCREW HAND PUMP TO BRACKET
14
NUT , Replaced By: N910113010004
17
PROTECTIVE PLATE
20
BRACKET BRACKET TO HEAT SHIELD
23
SCREW , Replaced By: N304017006016
26
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
29
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
32
SCREW BATTERY POS. CABLE TO BRACKET,PB004444
35
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
51
SUPPORT , Replaced By: A6884927216
52
SCREW GROUND STRAP TO CAB CROSS MEMBER M 10X25
53
NUT , Replaced By: N910113010000
54
DAMPING PAD FRONT EXHAUST PIPE,B 884219
55
CLAMPING PLATE. BASE PLATE FRONT EXHAUST PIPE,B 884219
56
SPACER TUBE FRONT EXHAUST PIPE,B 884219
57
HEX. HEAD SCREW. SCREW EXHAUST PIPE TO SUPPORT M 8X45
57
HEX. HEAD SCREW. SCREW EXHAUST PIPE TO SUPPORT M 8X40
58
WASHER TRAILER PLUG SOCKET TO BRACKET
59
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
60
INSULATING WASHER. INSULATION , Replaced By: A3094900037
61
SUPPORT EXHAUST PIPE TO SUPPORT
62
CLAMP REAR EXHAUST PIPE TO SUPPORT,D 250888
63
SCREW HAND PUMP TO BRACKET
64
NUT , Replaced By: N910113010004
65
EXHAUST MUFFLER
65
65
EXHAUST MUFFLER
65
EXHAUST MUFFLER
65
EXHAUST MUFFLER
66
CLAMP , Replaced By: A6734920140
67
SCREW , Replaced By: N304017008067
68
WASHER FRONT AND REAR EXHAUST PIPES TO MUFFLER
69
NUT , Replaced By: A1201420072
69
HEXAGON NUT SCREENING PLATE,5 163561
70
BRACKET EXHAUST MUFFLER,FRONT
71
SCREW BRACKET TO BUMPER,LEFT M 10X25
71
SCREW BRACKET TO FRAME M 10X28
74
NUT , Replaced By: N910113010000
77
RUBBER BUFFER EXHAUST MUFFLER
80
WASHER GROUND CABLE
83
NUT , Replaced By: N910113010000
86
SUPPORT
89
CLAMP EXHAUST MUFFLER TO SUPPORT
92
SCREW MOUNTING CLAMP TO BRACKET AND TO FRAME
95
WASHER TRAILER PLUG SOCKET TO BRACKET
98
NUT , Replaced By: A1201420072
98
HEXAGON NUT SCREENING PLATE,5 163561
98
NUT , Replaced By: N913004008001
101
FRONT EXHAUST PIPE (TAIL PIPE),B 984609
101
104
BRACKET TAIL PIPE TO SIDE MEMBER
107
SCREW BRACKET TO FRAME M 10X28
107
SCREW BRACKET TO BUMPER,LEFT M 10X25
110
NUT , Replaced By: N910113010000
113
RUBBER BUFFER EXHAUST MUFFLER
116
WASHER TRAILER PLUG SOCKET TO BRACKET
119
NUT , Replaced By: N910113010000
122
SUPPORT EXHAUST PIPE TO BRACKET
125
CLAMP REAR EXHAUST PIPE TO SUPPORT,D 250888
128
SCREW HAND PUMP TO BRACKET
131
NUT , Replaced By: N910113010004
