Поз.
Артикул
Описание
5
FRONT SPRING ,B 831781, Replaced By: A6883207102
8
SPRING LEAFNO.1,B 831781
11
SPRING LEAFNO.2,B 831781
14
SPRING LEAFNO.3,TO 688 320 10 02
17
SPRING LEAFNO.4
26
SPRING BOLTAM 10X105
29
NUT SPRING BOLT
35
SPACER TUBE , Replaced By: A0003213253
38
SCREW
41
NUT , Replaced By: N913004008001
44
RUBBER MOUNTING REAR SPRING TO SPRING SHACKLE AND TO SPRING REAR BRACKET
47
BUSHING FRONT SPRING TO FRONT-SPRING REAR BRACKET
47
BUSHING
50
SPACER TUBE O.D.,/HOLE DIA.,/I.D.,30 / 13MM(PLASTIC)
50
BUSHING FRONT SPRING TO FRONT-SPRING REAR BRACKET
53
SPACER TUBE SPRING SHACKLE TO SPRING REAR BRACKET 22 / 12,5 MM
56
WASHER REAR SPRING & SPRING SHACKLE TO REAR SPRING BRACKET
59
NUT , Replaced By: N910113018004
62
SCREW FRONT SPRING TO SPRING SHACKLE AND TO SPRING REAR BRACKET
65
NUT SUPPORT TO SIDE MEMBER
68
SHACKLE FRONT SPRING TO FRONT-SPRING REAR BRACKET
71
PLATE FRONT SPRINGS TO FRONT AXLE
74
U-BOLT FRONT SPRINGS TO FRONT AXLE 150 MM,B 914378
75
SHIM FRONT SPRINGS TO FRONT AXLE
77
NUT BRACKET TO BATTERY CASE
