Поз.
Артикул
Описание
14
LINE FROM BRAKE MASTER CYLINDER TO FRONT AXLE BRAKE HOSE,LEFT,D 047756
17
LINE FROM BRAKE MASTER CYLINDER TO FRONT AXLE BRAKE HOSE,RIGHT,D 047756
23
HOSE FRONT AXLE
23
23
BRAKE HOSE FRONT AXLE
26
RETAINING SPRING BRAKE HOSE TO BRACKET
29
BRACKET , Replaced By: A1265460643
32
LINE FROM BRAKE HOSE TO LEFT FRONT CALIPER
32
LINE FROM BRAKE HOSE TO RIGHT FRONT CALIPER
35
LINE PRESSURE RETAINING,B 891197
38
VALVE , Replaced By: A1214290134
38
VALVE , Replaced By: A1214290134
41
44
HOSE REAR AXLE
44
44
BRAKE HOSE REAR AXLE
47
RETAINING SPRING BRAKE HOSE TO BRACKET
50
DISTRIBUTOR REAR AXLE
53
SCREW SWITCH TO BRACKET 8X16
56
LINE FROM DISTRIBUTOR TO LEFT WHEEL BRAKE CYLINDER
59
LINE FROM DISTRIBUTOR TO RIGHT WHEEL BRAKE CYLINDER
62
CLIP BRAKE LINE TO CAB SUBSTRUCTURE,D 047756
62
CLAMP BRAKE LINE TO CAB SUBSTRUCTURE,D 070924
65
CLIP BRAKE LINE TO CAB SIDE MEMBER
68
BRACKET BRAKE LINE TO FIRE WALL
71
BRACKET LINE TO SIDE MEMBER
71
BRACKET , Replaced By: A6884287440
74
CLAMP LINE MOUNTING
74
CLAMP ,K 147121, Replaced By: N000000000319
77
SCREW COMPRESSED AIR LINE TO ENGINE MOUNTING SUPPORTING ARM
80
WASHER PLUG SOCKET TO BRACKET
83
LOCK WASHER CABLE TO FUSE BOX
86
NUT CLAMP TO BRACKET
89
INSULATING HOSE PROTECTION AGAINST SCORING, ORDER BY THE METER
92
BRACKET BRAKE HOSE TO SIDE MEMBER
95
SCREW BEARING BRACKET TO SIDE MEMBER M 14X1.5X28
98
SCREW BRACKET TO BUMPER,LEFT M 10X25
101
NUT , Replaced By: N910113010000
104
CLAMP BRAKE LINE MOUNTING
107
HOSE BRAKE LINE TO CAB SIDE MEMBER,D 065341
110
BRACKET BRAKE LINE TO REAR AXLE
113
BRACKET LINE MOUNTING
116
SCREW STEERING SHAFT BEARING TO CAB M 8X20
119
122
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
LINE FROM VALVE TO BRAKE HOSE,B 891197
