Поз.
Артикул
Описание
5
8
SCREW ALTERNATOR TO SUPPORT
11
WASHER ENGINE SUPPORTING ARM ON ENGINE SUPPORT
14
NUT ALTERNATOR TO SUPPORT
17
RUBBER MOUNTING FRONT, TO BE ADAPTED DURING ASSEMBLY
17
RUBBER MOUNTING ENGINE SUSPENSION
17
RUBBER MOUNTING FRONT,D 034636
20
SCREW GUSSET PLATE TO CROSS MEMBER M16 X 1.5 X 40
23
WASHER CONSOLE TO FRAME
26
ENGINE STAY RUBBER MOUNTING TO FRONT CROSS MEMBER
29
NUT SUPPORT TO SIDE MEMBER
32
32
41
41
44
SCREW , Replaced By: N304017012002
47
WASHER HUB CAP TO BRACKET
50
RUBBER MOUNTING
65
ENGINE STAY RUBBER MOUNTING TO ENGINE REAR SUPPORT
68
NUT BRACKET TO SIDE MEMBER M12X1.5
71
HEXAGON HEAD BOLT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER M14X1.5X40
74
WASHER IN ITS PLACE,YOU MAY ALSO USE MERCEDES-BENZ PART NO.: 360 990 18 40
77
HEXAGON HEAD BOLT. SCREW MOUNTING PARTS M 14X1.5X35
80
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
83
ENGINE CROSS MEMBER REAR
86
SUPPORT REAR
86
89
REINFORCEMENT RIGHT
89
REINFORCEMENT LEFT
92
HEXAGON HEAD BOLT BRACKET TO SIDE MEMBER M12X1.5X40
95
NUT BRACKET TO SIDE MEMBER M12X1.5
98
HEXAGON HEAD BOLT. SCREW BRACKET TO CONSOLE
101
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
