Поз.
Артикул
Описание
5
BRAKE HOSE LEFT AND RIGHT FRONT WHEEL BRAKE CYLINDERS
5
BRAKE HOSE LEFT AND RIGHT FRONT WHEEL BRAKE CYLINDERS
5
BRAKE HOSE LEFT AND RIGHT FRONT WHEEL BRAKE CYLINDERS
5
BRAKE HOSE FROM QUICK-RELEASE VALVE TO COMBINATION CYLINDER,RIGHT
5
BRAKE HOSE , Replaced By: A3844207248
8
CLAMP HOSE TO FITTING AND TO OIL TANK
11
FITTING
14
UNION NUT LINE CONNECTION, Replaced By: N000000006239
17
GLAND , Replaced By: A0019901967
18
BRAKE HOSE FROM FITTING TO LEFT COMBINATION CYLINDER,CONNECTION: "11"
18
BRAKE HOSE FROM FITTING TO LEFT COMBINATION CYLINDER,CONNECTION: "11"
18
BRAKE HOSE FROM RELAY VALVE TO COMBINATION CYLINDER
18
BRAKE HOSE FROM RELAY VALVE TO COMBINATION CYLINDER
18
HOSE , Replaced By: A3824207548
23
ELBOW FITTING LINE MOUNTING
26
ELBOW FITTING HOSE WIDTH, 9 MM,TO M 22
29
CONNECTOR FROM REAR BRAKE HOSE TO TRISTOP CYLINDER TO M 22
32
CONNECTOR HOSE WIDTH, 9 MM, TO M 22
35
CLAMP HOSE TO FITTING AND TO OIL TANK
38
LOCK REAR AXLE BRAKE HOSE,K 181360
41
TEST CONNECTION TIRE INFLATING CONNECTION KNORR
44
FITTING , Replaced By: A0019909871
46
ELBOW FITTING DIAPHRAGM CYLINDER,CONNECTION: "1,11"
46
ELBOW FITTING , Replaced By: A3849907071
47
FITTING QUICK BREATHER VALVE,REAR, CONNECTION: "23"
47
SCREW-IN FITTING OIL LINE CONNECTION
50
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
53
THRUST RING LOCKING VALVE
54
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
56
ADAPTER FITTING LINE CONNECTION TO ENGINE
59
TOOTHED WASHER SENDER UNIT TO BRACKET
62
WASHER COILED TUBE TO BRAKE LINE COUPLING SUPPORT
65
NUT BRACKET TO SIDE MEMBER
68
SCREW. UNION SCREW LINE CONNECTION
71
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
73
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
77
FITTING LOAD/NO-LOAD VALVE,CONNECTIONS: "10,21"
80
SCREW. UNION SCREW LINE CONNECTION
83
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
86
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
89
THRUST RING LOCKING VALVE
90
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
92
NUT BRACKET TO SIDE MEMBER
95
TOOTHED WASHER SENDER UNIT TO BRACKET
98
WASHER COILED TUBE TO BRAKE LINE COUPLING SUPPORT
