Поз.
Артикул
Описание
5
TANK POWER STEERING
8
FILTER ELEMENT ,D 441028D 523393
11
BRACKET
14
FILLER CAP
17
SEAL RING
20
OIL DIPSTICK ,D 523393
23
STRAP OIL TANK
26
BRACKET OIL TANK
29
SCREWM 10X20
32
SCREWM 10X20
35
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBERM 12X1.5X30
38
NUT BRACKET TO SIDE MEMBER M12X1.5
41
HOSE FROM OIL TANK TO SUCTION LINE
47
CLAMP , Replaced By: N000000000667
47
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
50
LINE SUCTION LINE TO OIL PUMP M22X1,5X1070-30,40BAR
53
HOLLOW SCREW POWER STEERING PUMP
56
SEAL RING ENGINE AIR COMPRESSOR,CONNECTION: "20"
59
LINE FROM PUMP TO HIGH PRESSURE HOSE M12X1,5X1150 - 121,60BAR
62
UNION NUT LINE CONNECTION, Replaced By: N000000006239
65
GLAND , Replaced By: A0019901967
68
HOLLOW SCREW LINE CONNECTION TO TRANSMISSION
68
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
71
SEALING RING. SEAL RING DELIVERY LINE TO STEERING
74
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
74
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
74
HOSE DELIVERY LINE TO PUMP
77
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO STEERING BOX
80
UNION NUT LINE CONNECTION, Replaced By: N000000006239
83
GLAND , Replaced By: A0019901967
86
BANJO UNION
89
HOLLOW SCREW LINE CONNECTION TO TRANSMISSION
89
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
92
SEALING RING. SEAL RING DELIVERY LINE TO STEERING
95
SEAL RING SOLENOID VALVE A 18X24
98
HOLLOW SCREW
101
LINE FROM STEERING GEAR TO OIL TANK
104
BANJO UNION COMPRESSED AIR LINE TO AIR COMPRESSOR
107
GLAND LINE CONNECTION
113
HOSE HIGH PRESSURE
116
CLAMP , Replaced By: N000000000667
116
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
116
CLAMP HOSE TO FITTING AND TO OIL TANK
143
BRACKET HYDRAULIC LINE MOUNTING PARTS
146
CLAMP BATTERY POS. CABLE TO BRACKET
146
CLAMP DELIVERY AND SUCTION LINES TO FRAME 22/15
146
CLAMP DELIVERY AND SUCTION LINES TO FRAME
146
CLAMP DELIVERY AND SUCTION LINES TO FRAME 12/15
146
CLAMP DELIVERY AND SUCTION LINES TO FRAME 12/15
146
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
149
SCREW BRACKET TO CAB REAR PANEL M 8X20
152
SCREW. HEXAGON HEAD BOLT BUZZER TO WINDOW LEVEL GIRDER M6X25
161
NUT HORN TO BRACKET M8
164
NUT BRACKET TO FIRE WALL
999
WASHER PLUG SOCKET TO BRACKET
