Поз.
Артикул
Описание
5
FRONT SPRING 5-LEAF
8
SPRING LEAF 5-LEAF
11
BUSHING
11
BUSHING
14
SPRING LEAF 5-LEAF
17
SPRING LEAF 5-LEAF
20
SPRING LEAF 5-LEAF
23
SPRING LEAF 5-LEAF
29
SPACER TUBE SPRING CLAMP TO SPRING LEAF,5 484790
32
SCREW SHIFT LEVER
35
NUT SPRING CLAMP TO SPRING LEAF
38
SHIM
41
SHIM
44
SHIM ,W181529
50
SPACER
53
SPRING BOLT ,5 711071
53
SPRING BOLT FRONT SPRINGS TO FRONT AXLE
56
NUT , Replaced By: N910113012005
62
PLATE FRONT SPRINGS TO FRONT AXLE
65
HELPER SPRING SPRING STOP TO FRAME BOTTOM SIDE
68
U-BOLT FRONT SPRINGS TO FRONT AXLE 240 MM,W181528
68
U-BOLT FRONT SPRINGS TO FRONT AXLE 230 MM
68
U-BOLT FRONT SPRINGS TO FRONT AXLE 250 MM
68
U-BOLT FRONT SPRINGS TO FRONT AXLE 210 MM
71
NUT STABILIZER TO FRONT AXLE
72
WASHER COILED TUBE TO BRAKE LINE COUPLING SUPPORT
74
SHACKLE FRONT SPRING SUSPENSION,REAR
77
BUSHING
77
BUSHING
80
SHACKLE PIN FRONT SPRING TO FRONT SPRING FRONT BRACKET
80
SHACKLE PIN FRONT SPRING TO SPRING SHACKLE AND TO SPRING REAR BRACKET
86
GREASE NIPPLE
89
WASHER AS REQUIRED
89
WASHER AS REQUIRED 4.2 MM
89
WASHER AS REQUIRED 4.20 MM
89
WASHER AS REQUIRED 4.00 MM
92
SEAL RING SPRING SUSPENSION
95
BOLT SPRING SHACKLE TO SPRING REAR BRACKET
98
WASHER GROUND CABLE
101
NUT SPRING CLAMP
