Поз.
Артикул
Описание
5
5
8
AIR DEHYDRATORTO 693 420 75 71
8
ANTI-FREEZE DEVICETO 693 420 73 71
11
REPAIR KIT. AIR CLEANERTO 693 420 75 71
11
ANTI-FREEZE DEVICE REPAIR KIT
14
MUFFLER VALVE CENTRE TO 693 420 75 71
14
MUFFLER
18
VALVE FOUR-CIRCUIT PROTECTIVE VALVE TO 693 420 73 71
18
VALVE FOUR-CIRCUIT PROTECTIVE VALVE TO 693 420 75 71
21
VALVE EXHAUST BRAKE TO382 42073 71, NOT USED
21
24
SOLENOIDTO 386 997 73 36
27
SEAL RINGTO 693 420 73 71
30
GASKET KIT REPAIR KIT TO A 664 431 01 15 KNORR
30
ANTI-FREEZE DEVICE. REPAIR KIT AIR DEHYDRATOR TO 693 420 73 71
33
GASKET KIT AIR DEHYDRATOR TO 000 430 19 15
36
PARTS KIT PRESSURE REGULATOR TO 693 420 73 71,75 71
36
TEST CONNECTION TIRE INFLATING VALVE, TO 382 420 74 71/ 72 71
39
REPAIR KIT VALVE TO 695 420 75 71
39
ANTI-FREEZE DEVICE. REPAIR KIT VALVE TO 693 420 73 71
39
REPAIR KITTO A 664 431 01 15 KNORR
39
REPAIR KIT AIR DEHYDRATOR TO 382 420 75 71
42
REPAIR KIT VALVE TO 000 420 30 71
45
REPAIR KIT FOUR-CIRCUIT PROTECTIVE VALVE TO 693 420 75 71
45
REPAIR KIT PRESSURE REGULATOR TO 693 420 73 71
48
RS PROTECTION VALVE FOUR-CIRCUIT PROTECTIVE VALVE TO 693 420 75 71,D 333550
48
GASKET KIT FOUR-CIRCUIT PROTECTIVE VALVE TO 693 420 75 71,D 333549
52
SCREW. UNION SCREW , Replaced By: A0009973734
55
LOCK , Replaced By: A0009945448
58
SEAL RING , Replaced By: A0009940747
61
SCREW. UNION SCREW LINE CONNECTION
64
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
67
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
70
HEXAGON HEAD BOLT. SCREW VIBRATION ABSORBER TO CONSOLE M 12X1.5X60
70
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBERM 12X1.5X30
73
NUT BRACKET TO SIDE MEMBER M12X1.5
