Поз.
Артикул
Описание
38
PLASTIC TUBE2X4MM, ORDER BY THE METER
38
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
41
UNION NUT BLEEDING, FROM IDENT NO. 5 033767,EXCEPT FOR 5 039977
41
UNION NUT
44
GLAND BLEEDING, FROM IDENT NO. 5 033767,EXCEPT FOR 5 039977
44
GLAND , Replaced By: A0019901667
47
SLEEVE LEAK LINE
65
ELBOW FITTINGTO M22 / 4MM / M12X1,5 / VOSS 230
71
ELBOW FITTINGTO M10 / 4MM /VOSS 230
71
ELBOW FITTING HOSE WIDTH, 4 MM,TO M 22
86
UNION SCREW SPRING LOAD ACCUMULATOR CYLINDER M10X1 / VOSS 230,D 259885
89
SEAL RING SPRING LOAD ACCUMULATOR CYLINDER TO M10 / VOSS 230,D 259885
92
LOCK SPRING LOAD ACCUMULATOR CYLINDER TO M10 / VOSS 230,D 259885
98
VALVE 3/2-WAY VALVE
98
VALVE 3/2-WAY VALVE
99
REPAIR KITTO 003 997 14 36,WABCO 472 123 19 80
101
HOLLOW SCREW HEATING CONNECTION
101
HOLLOW SCREW HEATING CONNECTION
104
SEAL RING LINE CONNECTION
104
SEAL RING LINE CONNECTION
107
LOOM TIE ELECTRIC CABLE MOUNTING
107
LOOM TIE WIRING HARNESS FOR AIR CONDITIONING SYSTEM 205 MM
110
BRACKET 3/2-WAY VALVE
113
SCREW BRACKET TO SIDE MEMBER
116
NUT BRACKET TO SIDE MEMBER
119
SCREW VALVE TO BRACKET M 8X60
122
WASHER TRAILER PLUG SOCKET TO BRACKET
125
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
125
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
131
INSULATING HOSE COLOR CODE BLUE 2X0,01 MM
131
INSULATING HOSE8X0,01 MM
134
VALVE , Replaced By: A6934297144
134
VALVE (QUICK BREATHER VALVE) VARGA
134
VALVE (QUICK BREATHER VALVE) WABCO
134
VALVE QUICK-RELEASE VALVE KNORR
134
VALVE (QUICK BREATHER VALVE) VARGA
137
REPAIR KITTOA 382 429 70 44, A 693 429 71 44
137
REPAIR KITTO A 364 429 70 44
140
BRACKET QUICK-RELEASE VALVE
143
SCREW BRACKET TO CAB REAR PANEL M 8X20
146
NUT HORN TO BRACKET M8
149
WASHER TRAILER PLUG SOCKET TO BRACKET
152
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
155
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
158
SCREW PLUG RELAY VALVE,CONNECTION "20",RIGHT
161
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
173
HOLLOW SCREW FITTING LEFT AND RIGHT COMBINATION CYLINDERS, CONNECTION: "11,12",5 356525
176
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
179
SWITCH
179
SWITCH SUPPLY PRESSURE,5 966147
