Поз.
Артикул
Описание
11
BRAKE LINE COUPLING
14
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
14
NUT BRACKET TO SIDE MEMBER,XB209706
20
HEXAGON HEAD BOLT CONSOLE TO REAR CROSS MEMBER AND TO FRAME SIDE MEMBERS M 10X40
20
SCREW BRACKET TO RETARDER
38
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
38
THRUST RING LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
38
THRUST RING LOCKING VALVE
44
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
53
FITTING LOAD/NO-LOAD VALVE,CONNECTIONS: "10,21"
56
SCREW. UNION SCREW LINE CONNECTION
59
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
62
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
999
WASHER GROUND CABLE
