Поз.
Артикул
Описание
8
LINE AIR COMPRESSOR,PRESSURE REGULATOR, DEHYDRATOR 15X1.5 MM, LENGTH AVAILABLE: 3000 MM
16
UNION NUT BUTT SCREW CONNECTION
16
UNION NUT LINE CONNECTION
24
GLAND LINE CONNECTION
32
THRUST RING COMPRESSED AIR LINE TO AIR RESERVOIR AND TO T-FITTING
40
SEAL RING , Replaced By: N007603012121
48
BRAKE HOSE FROM AIR COMPRESSOR TO PRESSURE REGULATOR
48
BRAKE HOSE COMPRESSED AIR LINE TO COMPRESSED AIR LINE
56
FITTING , Replaced By: N003952015100
64
FITTING
72
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
80
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
88
UNION NUT
96
SLEEVE LEAK LINE
104
GLAND , Replaced By: A0019901667
112
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
120
AIR DEHYDRATORAEROFINER
128
BRACKET AIR DEHYDRATOR
136
BUSHING AIR DEHYDRATOR TO BRACKET
144
SUSPENSION BRACKET TO RADIATOR
152
NUT , Replaced By: N913004008001
160
FITTING
168
ELBOW FITTING LINE CONNECTION
184
CONNECTION FITTING , Replaced By: N003902018002
192
FITTING COMPRESSED AIR LINE TO AIR COMPRESSOR
200
PRESSURE REGULATOR
208
FITTING , Replaced By: N003952015100
216
FITTING
999
FITTING AIR RESERVOIR,CONNECTION: "27"
999
BRAKE HOSE
999
O-RING CHECK VALVE TO AIR RESERVOIR
999
ANTI-FREEZE DEVICE
999
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
