Поз.
Артикул
Описание
8
BRACKET BATTERY CASE TO CONSOLE,REAR
11
BRACKET BATTERY CASE TO CONSOLE,FRONT
14
BATTERY CASE
17
ANGLE BATTERY CASE TO BRACKET
20
SCREW END PIECE TO EXHAUST PIPE M 10X25
20
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
20
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
23
WASHER BRACKET TO CROSS MEMBER, UP TO CHASSIS A 059728 EXCEPT FOR A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059525,A 059526,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
26
NUT , Replaced By: N910113010000
29
SCREW BRACKET TO SIDE MEMBER
32
SPRING WASHER STEERING COLUMN BRACKET TO CAB
35
RIVETED NUT BRACKET TO UNDERRUN PROTECTION
38
PROTECTIVE PLATE BATTERY CASE,LONGITUDINAL
41
PROTECTIVE PLATE BATTERY CASE,LATERAL
44
RUBBER BUFFER BATTERY SUPPORT STOP
47
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
53
RAIL BATTERY LEFT SUPPORT
56
SCREW GUIDE TO STEERING COLUMN END,4 430730
59
NUT , Replaced By: N913002004001
62
BATTERY SUPPORT
65
MOUNTING FRAME BATTERY MOUNTING
68
HOOK BATTERY MOUNTING
71
NUTTO 000 466 38 02
74
FASTENER BATTERY CASE
77
SCREW LOCK TO BATTERY CARRIAGE
80
BOW BATTERY CASE LOCK
83
SCREW , Replaced By: N304017006020
86
NUT , Replaced By: N913004006001
89
CHAIN TO SECURE BATTERY CASE
