Поз.
Артикул
Описание
8
STEERING SUPPORT STEERING LS8
16
PITMAN ARM
24
NUT PITMAN ARM TO STEERING BOX ASSEMBLY M45X1.5
32
WASHER STEERING
40
ROD FROM PITMAN ARM TO FRONT AXLE
48
DRAG LINK END R.H. THREAD
56
DRAG LINK END L.H. THREAD
64
TUBE FROM HIGH PRESSURE HOSE TO STEERING, LENGTH AVAILABLE: 3000 MM
64
LINE , Replaced By: A0005516256
72
LINE SUCTION LINE
80
BRACKET LINE MOUNTING
88
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
96
CLAMP DELIVERY AND SUCTION LINES TO STEERING
96
CLAMP , Replaced By: A6739950001
104
SCREW COVERING TO SUPPORT
112
SCREW AT FILTER BRACKET
120
NUT AT FILTER BRACKET
