Поз.
Артикул
Описание
5
OIL PIPE (OIL FILLER PIPE)
8
CLAMP SAFETY VALVE AT BRACKET
11
SCREW PIPE CLAMP
11
SCREW , Replaced By: N304017008021
14
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
14
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
14
NUT , Replaced By: N913004008001
17
CAP OIL REFILLING
17
CAP OIL REFILLING
17
CAP OIL REFILLING
20
GASKET
20
GASKET , Replaced By: A1020180380
23
HOSE , Replaced By: A6205280182
26
CLAMP SUCTION LINE TO OIL PUMP 40-60X13 MM
26
CLAMP , Replaced By: N000000000671
29
ANGLE LINE MOUNTING
32
CLAMP WIRE CABLE TO SIDE MEMBER AND TO TRANSMISSION
35
SCREW OIL LINE TO CRANKCASE
38
NUT PUMP TO BRACKET
38
NUT , Replaced By: N913004006001
